Specifications
AMPLIFIER SECTION
Power Output (FTC) All channels 40 watts per channel min.
RMS. into 6 ohms two channel driven,
1,000 Hz with no more than 5 % total
harmonic distortion.
Continuous power output (DIN)
All channels 30 watts per channel min.
RMS. into 6 ohms two channel driven,
1,000 Hz
Continuous Power output (EIAJ)
All channel 45 watts per channel min.
RMS. into 6 ohms two channel driven,
1,000 Hz
Dynamic Power 6 ohms: 42 W (L/R)
8 ohms: 35 W (L/R)
Total Harmonic Distortion 5 % at rated power
0.2 % at 1 watt output
IM Distortion 5 % at rated power
0.2 % at 1 watt output
Damping Factor 40 at 8 ohms
Input Sensitivity and Impedance
VIDEO 1 DIGITAL INPUT (OPT) –21 to –15 dBm
VIDEO 2 DIGITAL INPUT (COAX) 0.5 Vp-p, 75 ohms
TUNER SECTION
Tuning Range FM: 87.50 to 108.00 MHz (50 kHz steps)
AM: (North American and South American models)
530 to 1710 kHz (10 kHz steps)
Usable Sensitivity FM: Mono 11.2 dBf, 1.0 µV (75 ohms IHF)
0.9 µV (75 ohms DIN)
Stereo 17.2 dBf, 2.0 µV (75 ohms IHF)
23 µV (75 ohms DIN)
AM: 30 µV
50 dB Quieting Sensitivity FM: Mono 17.2 dBf, 2.0 µV (75 ohms)
Stereo 37.2 dBf, 20.0 µV (75 ohms)
Capture Ratio FM: 2.0 dB
Image Rejection Ratio FM: (North American and South American models)
40 dB
AM: 40 dB
DVD SECTION
Signal readout system Optical non-contact
Linear velocity 3.49 m/s (Single Layer)
3.84 m/s (Dual Layer)
Error correction system Reed Solomon Product Code
Signal system North American model: NTSC
Other models: PAL/Auto
Regional restriction code USA and Canadian area: 1
European area: 2
South-east Asian area: 3
Australian and South American area: 4
PRC: 6
Laser Semiconductor laser, wavelength 650 nm
Frequency response 10 Hz to 44 kHz (96 kHz)
Signal-to-noise ratio (digital audio) More than 100 dB
Audio dynamic range (digital audio) More than 93 dB
Harmonic distortion (digital audio) Less than 0.025%
Wow and flutter Below threshold of measurability
Operating conditions Temperature: 5°C to 35°C (41°F to 95°F),
Operation status: Horizontal
GENERAL
Power Supply Rating
(North American and South American models)
and Power Consumption AC 120 V, 60Hz 2.0 A
(Other models)
AC 120V, 60Hz 170 W
AC 230-240 V, 50Hz 170 W
Specifications and features are subject to change without notice.
LINE (VIDEO 1, VIDEO 2/CDR/PC, TV/LINE, TAPE/MD/HD)
200 mV/50 kohms
Composite (VIDEO 1, VIDEO 2/CDR/PC)
1 Vp-p, 75 ohms
S-VIDEO (VIDEO 1, VIDEO 2/CDR/PC)Y: 1 Vp-p, 75 ohms
C: 0.28 Vp-p, 75 ohms
Output Level and Impedance
DIGITAL OUTPUT (OPT) –21 to –15 dBm
REC OUT (TAPE/MD/HD, VIDEO 2/CDR/PC)
200 mV, 2.2 kohms
PRE OUT (SUBWOOFER) 1 V, 470 ohms
Composite (MON OUT, VIDEO 1) 1 Vp-p, 75 ohms
S-VIDEO (MON OUT, VIDEO 1) Y: 1 Vp-p, 75 ohms
C: 0.28 Vp-p, 75 ohms
COMPONENT VIDEO OUTPUT Y: 1.0 Vp-p, 75 ohms
(Except European model) PB/PR: 0.7 Vp-p, 75 ohms
RGB (European model) 0.7 Vp-p, 75 ohms
Frequency Response 20 to 30,000 Hz : +/– 0.8 dB
Acoustic Control 1: +9 dB at 120 Hz
2: +9 dB at 120 Hz
+6 dB at 10,000 Hz
Signal-to-noise Ratio 100 dB (0.5 V INPUT LINE)
Muting –50 dB
Dimensions (W x H x D)
435 × 101 × 428 mm (17
1
/
8
× 4 × 16
13
/
16
ins.)
Weight 8.8 kg (19.4 lb.)
(Other models)
522 to 1611 kHz (9 kHz steps)
(Other models)
85 dB
IF Rejection Ratio FM: 90 dB
AM: 40 dB
Signal-to-noise Ratio FM: Mono 73 dB, IHF
Stereo 67 dB, IHF
AM: 40 dB
Alternate Channel Att. (+/– 400 kHz) FM: Mono 55 dB, IHF
Selectivity FM:
50 dB, DIN
55dB, IHF
AM Suppression Ratio FM: 50 dB
Harmonic Distortion FM: Mono 0.2 %
Stereo 0.3 %
AM: 0.7 %
Frequency response FM: 30 to 15,000 Hz (+/– 1.0 dB)
Stereo Separation FM: 45 dB at 1,000 Hz
30 dB at 100 to 10,000 Hz
Stereo Threshold FM: 17.2 dBf, 20 µV (75 ohms)
