Onkyo DV-SP500 Service Manual

DV-SP500
EXPLODED VIEW (LOADING MECHANISM) / PARTS LIST
EXPLODED VIEW (LOADING MECHANISM) / PARTS LIST
A
A
To DVDM
CN151
2
8
8
8
12
23
13
17
16
15
14
20
18
19
9
1
11
10
6
8
Lubricating Oil
Lubricating Oil
GYA1001
GYA1001
GEM1036
GEM1036
Lubricating Oil
GYA1001
REF.NO
REF.NO
PART NO.
PART NO.
DESCRIPTION
DESCRIPTION
REF.NO.
REF.NO.
PART NO.
PART NO.
DESCRIPTION
DESCRIPTION
12 VNL1918
1 VNP1836
13 VNL1919
2 VXX2782
14 VNL1921
6 VDA1864
15 VNL1922
8 VEB1327
16 VNL1923
9 VEB1328
17 VNL1925
10 VNE2253
18 VNE2251
11 VNL1917
19 VNE2252
20 VNL1924
23
VNL1920
Z101 : DVD Mechanism DB-VLD301
Parts list
Loading PC board assy
Traverse mechanism assy
FFC 26P
Rubber
Belt
Stabilizer
Loading base
Float base DVD
Drive cam
Gear pulley
Loading gear
Drive gear
Lever switch
Clamper plate
Bridge
Clamper
Tray
