Onkyo FR-N3X - Page 54

3/13 PAGE
CD TRAY LOADING MECHANISM : DT1400
REF NO
.
PART NAME DESCRIPTION PART NO. NOTES
CD
B13 Loading motor ass'y --- 70300470B
CD
B16 Gear pulley --- 70333502B
CD
B17 Drive belt --- 70342118
CD
B18 Gear, Connector --- 70333503C
CD
B19 Gear, Loading --- 70333504E
CD
B21 Table disk-C --- 70366206
CD
B22 Clamper ass'y-C --- 70300654
CD
B24 Spring tray, Bias-C --- 70356536
CD DRAIVE UNIT : KSM-213CCM
REF NO
.
PART NAME DESCRIPTION PART NO. NOTES
CD
51 Motor chassis ass'y --- X-2625-877-1
CD
52 Motor gear ass'y --- X2625-769-1
CD
53 Sled shaft --- 2626-908-01
CD
54 Gear (A) (S) --- 24810023
CD
55 P2 × 3, Screw --- 7621-255-15
CD
56 Leaf switch --- 24840008
CD
57 Motor PC board --- 1639-678-12
CD
58 Connector 6pin --- 1-564-722-11
CD
61 KSS-213C, Pickup --- 8848-483-05
FR-N3X
EXPLODED VIEWS OF MECHANISM (MD)
The mechanical parts with no part number in the exploded views are not supplied.
MD MECHANISM : KMK-260EEO
REF NO
.
PART NAME DESCRIPTION PART NO. NOTES
MD
1
Motor Plate ass'y
--- ---
MD
2
Screw +PTT2.6 × 5 (S)
--- 7685-791-01
MD
3
L-SW Mount 2
--- ---
MD
4
Flexible flat cable (5 core)
--- 1792-100-31
MD
5
Gear (Relay B)
--- 2646-555-02
MD
6
Gear (Relay A)
--- 2646-554-01
MD
7
Frame ass'y, slot
--- X2646-726-1
MD
8
Spring(Slot arm), tension coil
--- 2646-563-01
MD
9
Slot Arm
--- 2646-556-01
MD
10
Flame ass'y, Road
--- ---
MD
11
Insulator
--- 2646-548-01
MD
13
Screw, Step
--- 2647-337-01
MD
14
Frame, Slide
--- ---
MD
15
Arm, head
--- 2646-559-02
MD
16
Sprig, Tension coil
--- 2646-562-01
MD
17
Spring, SP Tension
--- 2646-561-01
MD
18
Cam, Mode
--- 2646-560-02
MD
20
Grip (+P1.7 × 2.5 Type2)
--- 2627-529-01
MD
21
MD over write head
--- 8620-021-71
MD
23
MD mount PC board
--- ---
MD
24
Screw +PTT2.6 × 5 (S)
--- 7685-791-09
MD
26
Spring (Door arm), tension coil
--- 2646-545-01
MD
27
Case (lower)
--- ---
MD
30
Loading motor ass'y
--- X2626-328-1
MD
31
Precision screw (+P1.7 × 1.8 Type3)
--- 7627-852-38
MD
32
Screw +PTT2 × 3 (S)
--- 7685-780-01
MD
33
Loading ass'y
--- ---
