4/13 PAGE
MD
34
Case (Upper)
--- ---
MD
35
Screw +P2.6×4
--- 7621-259-25
MD
MD
51
Pan tapping screw (M1.4 × 3.5)
--- 3348-998-51
MD
52
Plate (Ｍ), Pre-load
--- 2167-550-01
MD
53
Wire, SL motor lead
--- ---
MD
54
Wire, SL motor lead
--- ---
MD
55
Sled motor ass'y
--- X2162-145-1
MD
56
Gear (ＭＤ)
--- 2646-571-01
MD
57
Plate (Ｍ), main shaft fixed
--- 2167-551-01
MD
58 Screw ass'y lead --- X2162-144-1
MD
59
Screw (B1.7 x 4)
--- 2646-358-11
MD
60
Spinlde motor ass'y
--- X2162-143-1
*
MD
61
D-SW mount 2
--- ---
MD
62
Chassis (Ｍ), mechanical
--- ---
MD
63
Shaft (Ｍ), guide
--- 2167-819-01
MD
64
Spring, rack
--- 2647-338-01
MD
65
Grip (1.7 × 2.5 type 2)
--- 2627-529-01
MD
66
Optical pickup, KMS-260E
--- 8-583-079-06
MD
67
Deck ass'y, mechanical
--- ---
MD
68
OP Flexible flat cable
--- 1669-180-11
MD
69
Flexible flat cable (7 core)
--- 1783-387-11
MD
* [NOTES] When you need exchange of the Spinlde motor ass'y, please exchange Mechanism ASSY and correspond.
MD MOUNT (PCB ASSY)
The mechanical parts with no part number in the exploded views are not supplied.
REF NO
