5/13 PAGE
MD
CN104
Connector, FFC/FPC (4P)
--- 1778-283-11
MD
CN105
Connector, FFC/FPC ((7P)
--- 1779-345-11
MD
CN106
Connector, FFC/FPC (5P)
--- 1779-353-21
MD
S
W1--SW
4
Push switch (1key)
--- 1771-092-21
MD
SW5
2pin push switch (2key)
--- 1771-327-11
MD
---
L-SW mount 2, PC board
--- ---
MD
---
D-SW mount 2, pC board
--- ---
PRINTED CIRCUIT BOARD PARTS LIST FR-N3X
<DT> : Taiwanese model only
<GT> : Aisian model only
<GK> : Korean model only
<GR> : Chinese model only
U1 PREAMPLIFIER PC BOARD (NAAF-7585-1B/1C)
REF NO
.
PART NAME DESCRIPTION PART NO. NOTES
U1
Q301 IC NJM4565M-D 22241383R2
U1
Q321 IC NJM2100M 22240608R1
U1
Q451 IC M62433FP 22241807R3
U1
Q941 IC(REGULATOR) NJM78M06FA 222780065JRC
U1
Q941A HEAT SINK RAD-157 27160491
U1
Q941B SCREW 3P+10FN(BC) 82143010
U1
Q942 IC(REGULATOR) NJM79M06FA 222790065JRC
U1
Q942A HEAT SINK RAD-157 27160491
U1
Q942B SCREW 3P+10FN(BC) 82143010
U1
Q943 IC(REGULATOR) MPC29M12HF 22278012ENE
U1
Q944 IC(REGULATOR) NJM78L05A 222780053JRC
U1
Q303 TR 2SD1468S-R 2215024 or
U1
Q303 or TR 2SD1468S-S 2215025
U1
Q304 TR 2SD1468S-R 2215024 or
U1
Q304 or TR 2SD1468S-S 2215025
U1
Q323 TR 2SD1468S-R 2215024 or
U1
Q323 or TR 2SD1468S-S 2215025
U1
Q324 TR 2SD1468S-R 2215024 or
U1
Q324 or TR 2SD1468S-S 2215025
U1
Q453 TR RN1441 2215410R2
U1
Q454 TR RN1441 2215410R2
U1
Q493 TR RN2402 2214530R2
U1
Q494 TR 2SA1162-GR 2214375R2
U1
Q495 TR 2SC2712-GR 2213145R2
U1
D491 C-DIODE 1SS355 223269R2 or
U1
D491 or C-DIODE 1SS352 223234R2
U1
D492 C-DIODE 1SS355 223269R2 or
U1
D492 or C-DIODE 1SS352 223234R2
U1
D941 C-DIODE 1SS355 223269R2 or
U1
D941 or C-DIODE 1SS352 223234R2
U1
D942 C-DIODE 1SS355 223269R2 or
U1
D942 or C-DIODE 1SS352 223234R2
U1
D943 C-DIODE 1SS355 223269R2 or
U1
D943 or C-DIODE 1SS352 223234R2
U1
D944 C-DIODE 1SS355 223269R2 or
U1
D944 or C-DIODE 1SS352 223234R2
U1
C252 VR C CE04W50V-3.3M(VR) 394680337
U1
C254 VR C CE04W50V-3.3M(VR) 394680337
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
