■ HTP-780 (SKF-780, SKC-780, SKR-780, SKB-780)
a Keyhole slots
These keyhole slots can be used to wall-mount the
speaker. See “Wall Mounting” for mounting instruc-
tions (➔ 14).
b Speaker terminals
These push terminals are for connecting the speaker to
the HT-R680 with the supplied speaker cables.
The supplied speaker cables are color-coded for easy
identification. Simply connect each cable to the same-
colored positive speaker terminal.
Caution
• The front grilles are not designed to be removed so do
not attempt to remove them forcibly, as this will damage
them.
SKF-780 SKC-780
SKR-780/SKB-780
a
b
a
a
b
b
Front
Front Rear
Rear
Front
Rear
