Onkyo HT HT-S7300

70
En
■ Powered Subwoofer (SKW-770)
■ Front Speaker (SKF-680)
■ Center Speaker (SKC-680)
■ Surround/Surround Back Speaker
(SKR-680/SKB-680)
7.1ch Home Theater Speaker Package (HTP-680)
Type Bass-reflex
Input sensitivity/Impedance
140 mV/20 kΩ
Maximum output power
290 W (Dynamic power)
Frequency response 25 Hz to 150 Hz
Cabinet capacity 37 L (1.3 cubic feet)
Dimensions (W × H × D)
10-13/16" × 19-15/16" × 16-3/16"
275 mm × 507 mm × 411 mm
(incl. projection)
Weight 11.6 kg (25.6 lbs.)
Drivers unit 10" (25 cm) Cone Woofer
Power supply AC 120 V, 60 Hz
Power consumption 163 W
Type 2 Way closed box
Impedance 6Ω
Maximum input power 130 W
Sensitivity 81 dB/W/m
Frequency response 60 Hz to 50 kHz
Crossover frequency 4 kHz
Cabinet capacity 2.1 L (0.074 cubic feet)
Dimensions (W × H × D)
4-3/4" × 11-7/16" × 4"
120 mm × 290 mm × 102 mm
(incl. grille and projection)
Weight 1.1 kg (2.4 lbs.)
Drivers unit
4" (10 cm) Cone (Woofer) × 2
1" (2.5 cm) Balanced dome (Tweeter)
Termin a l Spring type color coded
Keyhole slot 2
Grille Fixed
Type 2 Way closed box
Impedance 6Ω
Maximum input power 130 W
Sensitivity 81 dB/W/m
Frequency response 60 Hz to 50 kHz
Crossover frequency 4 kHz
Cabinet capacity 2.1 L (0.074 cubic feet)
Dimensions (W × H × D)
11-7/16" × 4-13/16" × 4-7/16"
290 mm × 122 mm × 113 mm
(incl. grille and projection)
Weight 1.1 kg (2.4 lbs.)
Drivers unit
4" (10 cm) Cone (Woofer) × 2
1" (2.5 cm) Balanced dome (Tweeter)
Terminal Spring type color coded
Keyhole slot 2
Grille Fixed
Type Full-Range closed box
Impedance 6Ω
Maximum input power 130 W
Sensitivity 79 dB/W/m
Frequency response 70 Hz to 20 kHz
Cabinet capacity 2.1 L (0.074 cubic feet)
Dimensions (W × H × D)
4-3/4" × 11-7/16" × 4"
120 mm × 290 mm × 102 mm
(incl. grille and projection)
Weight 0.8 kg (1.8 lbs.)
Drivers unit 8 cm (3-1/4") Cone
Terminal Spring type color coded
Keyhole slot 2
Grille Fixed
