HT-R290
EV
<Note>
EV
Parts marked by "NSP" are generally unavailable because
EV
they are not in our Master Spare Parts List.
EV
EV
EV
EV
EV
EV
EV
EXPLODED VIEW PARTS LIST
EV
EV
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EV
[CHASSIS SCREW]
EV
A001 CHASSIS TX-SR307 1 27100532E
N
EV
A003 LEG (B) 4 27175464
N
EV
A005 CUSHION (ZUL) 4 28141877
EV
A007 SCREW 3TTB+8B(3BC) 4 838430088GR
EV
A009 HOLDER KGLS-8RT 3 27190503A
EV
A010 HOLDER KGPS-8RF 1 27191044
EV
A011 HOLDER KGLS-10RT 1 27190428A
EV
A013 HOLDER KGPS-14RF 2 27190802
EV
A015 HOLDER KGPS-14RF 1 27190802
EV
A017 HOLDER KGLS-16S 1 27190607
EV
A019 HOLDER KGPS-16RF 1 27190991
EV
A021 HOLDER KGLS-22S 2 27190369
EV
A025 SCREW 4TTC+8C(3BC) 4 830440089GR
EV
A030 HEAT SINK 390P-2 1 27160658
N
EV
A032 RETAINER (HL) 1 27142159
EV
A034 RETAINER (HR) 1 27142223A
EV
A036 SCREW 3TTB+8B(3BC) 4 838430088GR
EV
A038 SCREW 3TTB+8B(3BC) 2 838430088GR
EV
A040 SCREW 3TTB+8B(3BC) 3 838430088GR
EV
A041 CLIP CS-1U 1 27255004
EV
A042 SCREW 3TTB+8B(3BC) 2 838430088GR
EV
A043 SCREW 3TTB+8B(3CM)SR 1 801637
EV
A050 SCREW 3SMS8WSW+18B3CM 4 801636
EV
A054 SCREW 3TTB+8B(3BC) 1 838430088GR
EV
A055 TAPE TAPE(CLOTH-8U) 1 29110082
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
