U001
Q4400 IC NJM4580M-D 1 22241448R2
U001
Q4401 TR 2SC2235-Y(TPE6_F) 1 2211654T
U001
[NOTICE]
U001
Q6001, Q6002 and the surrounding parts have been changed as follows in the middle of production. Refer to SCHEMATIC-DIAGRAM-4(AMP. SECTION)
U001
Change C6120, C6121 and C6122 at the same time when Q6001 is changed.
U001
Q6001
IC STK-443-530-E 1 222148 BEFORE
U001
↓↓
U001
IC
STK-443-530N-E
1
222152
AFTER
U001
C6120 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
C6121 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
C6122 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
Change C6123, C6124 and C6127 at the same time when Q6002 is changed.
U001
Q6002
IC STK-443-530-E 1 222148 N BEFORE
U001
↓↓
U001
IC
STK-443-530N-E
1
222152
AFTER
U001
C6123 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
C6124 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
C6127 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
Q6010 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6011 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6012 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6013 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6014 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6017 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6021 TR 2SA1163-BL(TE85L_F) 1 2216756R2
U001
Q6022 TR 2SC2240-BL(TPE2_F) 1 2211406T
U001
Q6023 TR 2SC2240-BL(TPE2_F) 1 2211406T
