20/37 PAGE
PCB
S7644 PUSH SW NPS-111-S681 1 25035718
PCB
S7644 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7645 PUSH SW NPS-111-S681 1 25035718
PCB
S7645 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7646 PUSH SW NPS-111-S681 1 25035718
PCB
S7646 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
S7647 PUSH SW NPS-111-S681 1 25035718
PCB
S7647 or PUSH SW NPS-111-S677 ( 1) 25035714
PCB
E7501 RETAINER KANAGU(ｱｰｽ) 1 27141059
PCB
JL7501A WIRE HOL NSCT-3P894 1 25051107
PCB
JL7501B WIRE HOL NSCT-3P894 1 25051107
PCB
JL7502A WIRE HOL NSCT-5P896 1 25051109
PCB
JL7502B WIRE HOL NSCT-5P896 1 25051109
PCB
PCB
PCB
U8 DRIVER AMPLIFIER PC BOARD(NAAF-7866-2A/2B/2C)
PCB
U9 VIDEO & OPT TERMINAL PC BOARD(NAVD-7867-2A/2B/2C)
PCB
U10 REGULATOR PC BOARD(NAETC-7868-2A/2B/2C)
PCB
U11 TERMINAL PC BOARD(NAETC-7869--2A/2B/2C)
PCB
U12 SPEAKER TERMINAL PC BOARD(NAETC-7870-2A/2B/2C)
PCB
U15 S VIDEO TERMINAL PC BOARD(NAVD-7873-2A/2B/2C)
PCB
U16 TERMINAL PC BOARD(NAETC-7874-2A/2B/2C)
PCB
<Note> Parts are indicated collectively, without dividing for above-mentioned each substrate.
PCB
REF NO. NAME DESCRIPTION QTY PART NO. REMARKS
PCB
U281 PHT CP TORX179L 1 24120101
PCB
Q201 TR RN1241-A 1 2213631
PCB
Q201 or TR RN1241-B ( 1) 2213632
PCB
Q202 TR RN1241-A 1 2213631
PCB
Q202 or TR RN1241-B ( 1) 2213632
PCB
Q203 IC LA7956 1 22241759
PCB
Q204 TR KTA1267-GR 1 2215995
PCB
Q204 or TR 2SA933S-R ( 1) 2213354
PCB
Q205 TR KRA102M 1 2215770
PCB
Q205 or TR DTA114ES ( 1) 2213510
PCB
Q206 TR KRA102M 1 2215770
PCB
Q206 or TR DTA114ES ( 1) 2213510
PCB
Q207 TR RN1241-A 1 2213631
PCB
Q207 or TR RN1241-B ( 1) 2213632
PCB
Q208 TR RN1241-A 1 2213631
PCB
Q208 or TR RN1241-B ( 1) 2213632
PCB
Q209 TR KTA1267-GR 1 2215995
PCB
Q209 or TR 2SA933S-R ( 1) 2213354
PCB
Q210 TR RN1241-A 1 2213631
PCB
Q210 or TR RN1241-B ( 1) 2213632
PCB
Q211 TR RN1241-A 1 2213631
PCB
Q211 or TR RN1241-B ( 1) 2213632
PCB
Q212 IC LA7956 1 22241759
PCB
Q213 IC LA7956 1 22241759
PCB
Q281 IC 74HCU04F 1 222740046R2
PCB
Q5000 TR KTC3200-BL 1 2215896
PCB
Q5000 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5000 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5000 or TR 2SC1845-E ( 1) 2211733
PCB
Q5001 TR KTC3200-BL 1 2215896
PCB
Q5001 or TR 2SC1775A-E ( 1) 2210755
PCB
Q5001 or TR 2SC1775A-F ( 1) 2210756
PCB
Q5001 or TR 2SC1845-E ( 1) 2211733
