PCB
P7503Bor SOCKET NSCT-8P1841 ( 1) 25052054
PCB
P7503Bor SOCKET NSCT-8P1639 ( 1) 25051852
PCB
JL6803B SOCKET NSCT-5P97 1 25050269
PCB
JL6804B SOCKET NSCT-5P97 1 25050269
PCB
JL6805B SOCKET NSCT-4P96 1 25050268
PCB
JL9501A WIRE HOL NSCT-7P898 1 25051111
PCB
JL9501B WIRE HOL NSCT-7P898 1 25051111
PCB
PCB
U17 POWER AMPLIFIER PC BOARD(NAAF-7875-2A/2B/2C/2D/2E)
PCB
U18 TERMINAL PC BOARD(NAPS-78762A/2B/2C/2D/2E)
PCB
U19 POWER SUPPLY PC BOARD(NAPS-7877-2A/2B/2C/2D/2E)
PCB
U20 TERMINAL PC BOARD(NAPS-7878-2A/2B/2C/2D/2E)
PCB
U21 HOLDER PC BOARD (NA79-7879-2A/2B/2C/2D/2E)
PCB
U22 THERMAL SENSOR PC BOARD(NAETC-7880-2A/2B/2C/2D/2E)
PCB
U23 HOLDER PC BOARD(NAETC-7881-2A/2B/2C/2D/2E)
PCB
U24 POWER SWITCH PC BOARD(NASW-7882-2A/2B/2C/2D/2E)
PCB
U25 TERMINAL PC BOARD(NAETC-7884-2A/2B/2C/2D/2E)
PCB
U26 THERMAL SENSOR PC BOARD(NAETC-8256-2A/2B/2C/2D/2E)
PCB
<Notes> Parts are indicated collectively, without dividing for above-mentioned each substrate.
PCB
REF NO. NAME DESCRIPTION QTY PART NO. REMARKS
PCB
Q921 TR KTC3199-GR 1 2215864
PCB
Q921 or TR 2SC1740S-R ( 1) 2213284
PCB
Q921 or TR 2SC1740S-S ( 1) 2213285
PCB
Q921 or TR 2SC2458-GR ( 1) 2212115
PCB
Q6010 TR 2SC1740S-R 1 2213284
PCB
Q6010 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6011 TR 2SC1740S-R 1 2213284
PCB
Q6011 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6012 TR 2SC1740S-R 1 2213284
PCB
Q6012 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6013 TR 2SC1740S-R 1 2213284
PCB
Q6013 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6014 TR 2SC1740S-R 1 2213284
PCB
Q6014 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6020 TR 2SC1740S-R 1 2213284
PCB
Q6020 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6021 TR 2SC1740S-R 1 2213284
PCB
Q6021 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6022 TR 2SC1740S-R 1 2213284
PCB
Q6022 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6023 TR 2SC1740S-R 1 2213284
PCB
Q6023 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6024 TR 2SC1740S-R 1 2213284
PCB
Q6024 or TR 2SC1740S-S ( 1) 2213285
PCB
Q6030 TR KTD2061-Y 1 2203434
PCB
Q6030 or TR 2SC5171 ( 1) 2203010
PCB
Q6031 TR KTD2061-Y 1 2203434
PCB
Q6031 or TR 2SC5171 ( 1) 2203010
PCB
Q6032 TR 2SC5511-E 1 2203845 <402>, <8240>
PCB
Q6032 or TR KTD2061-Y ( 1) 2203434
PCB
Q6032 or TR 2SC5171 ( 1) 2203010
PCB
Q6032 TR KTD2061-Y 1 2203434 <420>
PCB
Q6032 or TR 2SC5171 ( 1) 2203010
PCB
Q6033 TR 2SC5511-E 1 2203845 <402>, <8240>
PCB
Q6033 or TR KTD2061-Y ( 1) 2203434
PCB
Q6033 or TR 2SC5171 ( 1) 2203010
