Onkyo HT-R494 - Page 108

39/39 PAGE
1
P8621 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8621 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8631 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8631 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8631 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8641 SOCKET 51U019S-3HFDN-BD-SM 1 25053549R3
1
P8641 or SOCKET HDMI(47266-4101) ( 1) 25053389R3
1
P8641 or SOCKET TCX3423-311387 ( 1) 25060513R3
1
P8902 PLUG NPLG-2P915 1 25055962R2
1
P9011B PLUG NPLG-5P918 1 25055965R2
U005 BARF-1764-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[TRANS COIL]
1
L780 CORE BLM15PX181SN1D 1 2350033R1
1
L782 CORE BLM15PX181SN1D 1 2350033R1
1
L783 EMI SUPPRESSION FILTER BK1608LL241-T 1 230959R1
1
L784 EMI SUPPRESSION FILTER BK1608LL241-T 1 230959R1
1
L785 EMI SUPPRESSION FILTER BK1608LL241-T 1 230959R1
1
Q781 BT MODULE HRM1034 1 24150126R2 N
[CAPACITOR]
1
C786 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 1 332011045R1
1
C787 CHIP TYPE CERAMIC CAPACITOR CK725B1H-103K0 1 332031035R1
1
C790 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K0 1 332011045R1
1
C791 CHIP TYPE CERAMIC CAPACITOR CK725B1H-103K0 1 332031035R1
[RESISTOR]
1
R784 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 1 435032214R1
1
R785 CHIP TYPE CARBON RESISTOR RN72K1J-220JE 1 435032204R1
1
R786 CHIP TYPE CARBON RESISTOR RN72K1J-220JE 1 435032204R1
1
R787 CHIP TYPE CARBON RESISTOR RN72K1J-101JE 1 435031014R1
1
R788 CHIP TYPE CARBON RESISTOR RN72K1J-103JE 1 435031034R1
1
R792 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
R793 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 1 435032214R1
1
R794 CHIP TYPE CARBON RESISTOR RN72K1J-221JE 1 435032214R1
1
R795 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
[SW TRM]
1
P780B PLUG SM09B-SRSS-TB 1 25056386R2
