Onkyo HT-R494

16/39 PAGE
1
P6003B WIRE HOL NSCT-9P900 1 25051113
1
P6003Bor WIRE HOL CHD-2.5-9 ( 1) 25053543
1
P6005A WIRE HOL NSCT-5P896 1 25051109
1
P6005Aor WIRE HOL CHD-2.5-5 ( 1) 25053541
1
P6005B WIRE HOL NSCT-5P896 1 25051109
1
P6005Bor WIRE HOL CHD-2.5-5 ( 1) 25053541
P6080 PLUG NPLG-2P29 1 25055038
P6081 PLUG NPLG-2P29 1 25055038
P6082 PLUG NPLG-2P29 1 25055038
P6083 PLUG NPLG-2P29 1 25055038
P6084 PLUG NPLG-2P29 1 25055038
P6085 PLUG NPLG-2P29 1 25055038
P6086 PLUG NPLG-2P29 1 25055038
1
P6104 HOLDER HOLDER(CLAMP) 1 27190540-1
P6201 PLUG NPLG-5P152 1 25055168
1
P6400A CRIMP CORD ASSEMBLY CLIMP AS 1 2069925080UL
1
P6401A CRIMP CORD ASSEMBLY CRIMP AS 1 2069925142UL
1
P6402A CRIMP CORD ASSEMBLY CRIMP AS 1 2069925226UL
1
P6600A WIRE HOL NSCT-7P898 1 25051111
1
P6600Aor WIRE HOL CHD-2.5-7 ( 1) 25053542
1
P6600B WIRE HOL NSCT-7P898 1 25051111
1
P6600Bor WIRE HOL CHD-2.5-7 ( 1) 25053542
P6601 TERMINAL NTM-4PDMNRR414 1 25060486
P6606 TERMINAL NTM-10PDMLR444 1 25060523
P7003B PLUG NPLG-7P135 1 25055151
P7201 ST JACK MSJ-064-05A SR 1 25045783
1
P7202 TRM-423(SCREW) NEJITANSI ST3 1 25060495
P8001B SOCKET NSCT-23P2414 1 25052517
P8002B SOCKET NSCT-17P2408 1 25052511
RL6430 RELAY NRL-1P10A-DC12-196 1 25065707
RL6440 RELAY NRL-1P10A-DC12-196 1 25065707
RL6600 RELAY NRL-2P5A-DC24-129 1 25065563A
RL6601 RELAY NRL-2P5A-DC24-129 1 25065563A
RL6602 RELAY NRL-2P5A-DC24-129 1 25065563A
RL6603 RELAY NRL-2P5A-DC24-129 1 25065563A
U002 BADIS-1732-1A : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D2041 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2041 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2042 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2042 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2101 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2101 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2102 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2102 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2103 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2103 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2104 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2104 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
D2301 DIODE G10XB80-02-60A-T16 1 22380378F
D2301 or DIODE D5SBA60 ( 1) 22380070F
1
D2302 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2302 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2303 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D2303 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D2304 ZENER DIODE DZ2J062M0L 1 224760620R2
1
D2304 or ZENER DIODE UDZS6.2B ( 1) 224550620R2
1
D2305 DIODE RB050M-30GTR 1 22380373R2
1
D5000 ZENER DIODE DZ2J056M0L 1 224760560R2
1
D5000 or ZENER DIODE UDZS5.6B ( 1) 224550560R2
1
D5001 ZENER DIODE DZ2J056M0L 1 224760560R2
