Onkyo HT-R494

18/39 PAGE
1
Q5042 TRANSISTOR INC6006AP1-T111 1 2217990R2
1
Q5050 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q5051 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q5052 TRANSISTOR 2SC2412K-R 1 2214653R2
1
Q6010 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6011 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6012 TRANSISTOR 2SC2713-BL 1 2213136R2
1
Q6020 TRANSISTOR 2SA1163-BL(TE85L_F) 1 2216756R2
1
Q6021 TRANSISTOR 2SA1163-BL(TE85L_F) 1 2216756R2
1
Q6022 TRANSISTOR 2SA1163-BL(TE85L_F) 1 2216756R2
Q6030 TRANSISTOR TTC004B_Q(S 1 2218022
Q6031 TRANSISTOR TTC004B_Q(S 1 2218022
Q6032 TRANSISTOR TTC004B_Q(S 1 2218022
Q6040 TRANSISTOR TTA004B_Q(S 1 2218012
Q6041 TRANSISTOR TTA004B_Q(S 1 2218012
Q6042 TRANSISTOR TTA004B_Q(S 1 2218012
1
Q7501 HYBRID IC ML9208A-13GA 1 22242772R3
Q7502 FLUORESCENT TUBE 16-BT-168GNK 1 212279
1
Q7502A HOLDER (FL) 1 27191222C
1
Q7503 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q7503 or TRANSISTOR 2SC2712-GR ( 1) 2213145R2
1
Q7504 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q7504 or TRANSISTOR 2SC2712-GR ( 1) 2213145R2
1
Q7533 TRANSISTOR KTC3875-GR 1 2216175R2
1
Q7533 or TRANSISTOR 2SC2712-GR ( 1) 2213145R2
Q7541 REMOTE SENSOR IRM-3638M3S28 1 24130026
1
Q7653 TRANSISTOR DTC123JKA 1 2216690R2
1
Q7655 TRANSISTOR DTC123JKA 1 2216690R2
1
Q7801 HYBRID IC NJM4580CG 1 22242922R2
1
Q7803 TRANSISTOR RTAN430C-T112-1 1 2217780R2
1
Q7807 TRANSISTOR KRA102S 1 2216220R2
1
Q7808 TRANSISTOR KRC102S 1 2216190R2
1
Q7960 TRANSISTOR KTA1661-Y 1 2217864R2
1
Q7960 or TRANSISTOR INA5001AP1-T111 ( 1) 2218030R2
1
Q7961 TRANSISTOR 2SC2712-GR 1 2213145R2
1
Q7962 TRANSISTOR KRA102S 1 2216220R2
1
Q9011 TRANSISTOR KRC105S 1 2217290R2
1
Q9011 or TRANSISTOR RN1405 ( 1) 2214500R2
1
Q9011 or TRANSISTOR DTC123JKA ( 1) 2216690R2
[TRANS COIL]
1
L1 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
L2 CHIP TYPE CARBON RESISTOR RN72K1J-000JE 1 435030004R1
1
L2000 CHOKE COIL LBC2518T2R2M 1 231364M022R2
1
L2001 CHOKE COIL LBC2518T470M 1 231364M470R2
1
L2052 CHOKE COIL LBC2518T470M 1 231364M470R2
1
L2053 EMI SUPPRESSION FILTER BK1608HS102-T 1 230955R2
1
L3 RF COIL SDCL1608CR33JTDF 1 233557R1
1
L3 or RF COIL HK1608R33J-T ( 1) 233559R1
1
L4 RF COIL SDCL1608CR10JTDF 1 233556R1
1
L4 or RF COIL HK1608R10J-T ( 1) 233558R1
L5 ANTENNA COIL K7-D 1 232212
1
L7532 CHOKE COIL LBC2518T2R2M 1 231364M022R2
T9002 POWER TRANSFORMER NPT-1520JQ 1 2301812A !
X1 CRYSTAL HC-49S 9B12.000MHz 1 3010533
[CAPACITOR]
1
C1 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-101J1 1 342101014R1
1
C12 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-090D1 1 342100902R1
1
C13 CHIP TYPE CERAMIC CAPACITOR CK725B1C-104K1 1 332121045R1
1
C2 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-220J1 1 342102204R1
1
C2001 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2012 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2015 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2021 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2022 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
1
C2031 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-330J1 1 342103304R1
1
C2032 CHIP TYPE CERAMIC CAPACITOR CC725CH1H-330J1 1 342103304R1
1
C2041 CHIP TYPE CERAMIC CAPACITOR CK725F1E-104Z1 1 332161040R1
