Onkyo HT-R494 - Page 94

25/39 PAGE
1
S7632 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7633 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7634 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7635 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7636 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7637 PUSH SWITCH NPS-111-S681 1 25035718T
1
S7638 PUSH SWITCH NPS-111-S681 1 25035718T
U004 BAPRC-1758-1D : NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
1
D3402 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D3402 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7001 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7001 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7002 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7002 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7003 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7003 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7004 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7004 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7005 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7005 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7006 DIODE CUS357 1 223320R2 N
1
D7006 or CHIP TYPE DIODE 1SS357 ( 1) 223281R2
1
D7007 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7007 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7011 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7011 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D7012 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D7012 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D8002 ESD IMSA-6802-01Y901_1608SIZE 1 4000255AR1
1
D8151 DIODE CUS357 1 223320R2 N
1
D8151 or CHIP TYPE DIODE 1SS357 ( 1) 223281R2
1
D8201 DIODE CUS357 1 223320R2 N
1
D8201 or CHIP TYPE DIODE 1SS357 ( 1) 223281R2
1
D8702 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D8702 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D8902 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D8902 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D8906 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D8906 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D8907 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D8907 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
D8951 DIODE CUS357 1 223320R2 N
1
D8951 or CHIP TYPE DIODE 1SS357 ( 1) 223281R2
1
D8962 DIODE RB050M-30GTR 1 22380373R2
1
D8963 DIODE RB050M-30GTR 1 22380373R2
1
D8964 CHIP TYPE DIODE 1SR154-400 1 22380284R2
1
D8965 CHIP TYPE DIODE DA2J10100 1 223303R2
1
D8965 or CHIP TYPE DIODE 1SS352 ( 1) 223234R2
1
Q1004 HYBRID IC PCM1690DCAR 1 22242599R2
1
Q1005 HYBRID IC PCM9211PTR 1 22242703R2
1
Q1007 HYBRID IC 74VHC4040FT 1 22274040E1R2TO
1
Q1008 HYBRID IC TC7WH241FU(TE12L_F) 1 22242076R2TO
1
Q1090 HYBRID IC MM3404A50NRE 1 22242701R2
1
Q1091 HYBRID IC S-1333A33-M5T1U3 1 22242934R2
1
Q3111 HYBRID IC S-13A1A33-U5T1U3 1 22242844R2
1
Q3112 HYBRID IC XC25BS8040MR-G 1 22242954R2 N
1
Q3113 TRANSISTOR KRA307E 1 2218380R2
1
Q3113 or TRANSISTOR RN2107 ( 1) 2218290R2
1
Q3114 TRANSISTOR KRC407E 1 2218350R2 N
1
Q3114 or TRANSISTOR RN1107 ( 1) 2218260R2 N
