3
Precautions
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
NEC – NATIONAL ELECTRICAL CODE
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
ANTENNA
LEAD IN
WIRE
S2898A
21. Replacement Parts When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same characteristics
as the original part. Unauthorized substitutions may result in
fire, electric shock, or other hazards.
22. Safety Check
Upon completion of any service or repairs to the
appliance, ask the service technician to perform safety checks to
determine that the appliance is in proper operation condition.
23. Wall or Ceiling Mounting The appliance should be
mounted to a wall or ceiling only as recommended by the
manufacturer.
24. Heat The appliance should be situated away from heat
sources such as radiators, heat registers, stoves, or other
appliances (including amplifiers) that produce heat.
25. Liquid Hazards The appliance shall not be exposed to
dripping or splashing and no objects filled with liquids, such as
vases shall be placed on the appliance.
For U.S. models
Note to CATV system installer:
This reminder is provided to call the CATV system installer's
attention to Section 820-40 of the NEC which provides guidelines
for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the building,
as close to the point of cable entry as practical.
FCC Information for User
CAUTION:
The user changes or modifications not expressly approved by the
party responsible for compliance could void the users authority to
operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
FIGURE 1:
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL
ELECTRICAL CODE, ANSI/NFPA 70
For Canadian models
NOTE: THIS CLASS B DIGITAL APPARATUS COMPLIES
WITH CANADIAN ICES-003.
For models having a power cord with a polarized plug:
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
Modele pour les Canadien
REMARQUE: CET APPAREIL NUMÉRIQUE DE LA
CLASSE B EST CON-FORME À LA NORME NMB-003 DU
CANADA.
Sur les modèles dont la fiche est polarisée:
ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE
DANS LA BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQUAU FOND.

Other manuals for Onkyo HT-R500

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Onkyo HT-R500 and is the answer not in the manual?

Onkyo HT-R500 Specifications

Amplifier Section IconAmplifier Section
continuous average power output (FTC)100 watts per channel at 8 ohms
dynamic power output at 3 ohms230 watts × 2
dynamic power output at 4 ohms170 watts × 2
dynamic power output at 8 ohms115 watts × 2
total harmonic distortion0.08% at rated power
damping factor60 at 8 ohms
Input and Output Impedance IconInput and Output Impedance
digital input (optical 1, 2)0.5 Vp-p, 75 ohms
digital input (coaxial)0.5 Vp-p, 75 ohms
line (CD, VIDEO 1, 2, 3, TAPE)200 mV, 50 kohms
multichannel input (DVD FRONT L/C/R, SURR L/R)200 mV, 50 kohms
subwoofer input36 mV, 50 kohms
rec out (TAPE, VIDEO 1)200 mV, 470 ohms
pre out (subwoofer)1 V, 470 ohms
Tuner Section IconTuner Section
FM tuning range87.5-108.0 MHz
FM usable sensitivity (mono)11.2 dBf, 1.0 µV (75 ohms, IHF)
FM usable sensitivity (stereo)17.2 dBf, 2.0 µV (75 ohms, IHF)
FM signal-to-noise ratio (mono)76 dB, IHF
FM signal-to-noise ratio (stereo)70 dB, IHF
AM tuning range530-1, 710 kHz
AM usable sensitivity30 µV
AM signal-to-noise ratio40 dB
General IconGeneral
power supplyAC 120 V, 60 Hz
power consumption5.5 A
dimensions (W × H × D)17-1/8” × 5-7/8” × 14-13/16”
dimensions in mm (W × H × D)435 × 150 × 376 mm
weight21.4 lbs.
weight in kg9.7 kg
