Onkyo HT-R508

TX-SR505/505E
PRINTED CIRCUIT BOARD VIEWS-5
U07
POWER SUPPLY PC BOARD (NAPS-9150)
Component side
U08
TRANS. SEC. TERMINAL PC BOARD
(NAPS-9151)
Component side
U09
HEADPHONE JACK PC BOARD
(NAETC-9153)
Component side
U10
SWITCH PC BOARD (NASW-9157)
Component side
A
1
2
3
4
5
BCD
