Onkyo HT-R508

1/62 PAGE
HT-R508
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
EV
A001 F BRACKET SILVER 1 27111471B
EV
A002 SCREW 3TTB+8B(3CM)SR 5 801637
EV
A003 B PLATE --- 1 28133426
EV
A011 SCREW 3TTB+8B(3CM)SR 7 801637
EV
A012 SCREW 3TTB+8B(3CM)SR 2 801637
EV
A013 WIRE TIE BSK-1 7 260208
EV
A016 SCREW 3TTB+8B(3CM)SR 1 801637
EV
A017 WIRE TIE BINDER(CLAMPER)UL 2 260258
EV
A018 HOLDER KGLS-22S 1 27190369
EV
A020 HOLDER KGLS-16RT 2 27190511
EV
A021 HOLDER KGPS-16RF 4 27190991
EV
A022 HOLDER KGLS-10RT 1 27190428A
EV
A027 HOLDER HOLDER KGLS-18S 1 27190470
EV
A028 CLIP CS-1U 1 27255004
EV
A029 SCREW 3TTB+8B(3CM)SR 1 801637
EV
A030 SCREW 4TTC+8C(3BC) 4 830440089GR
EV
A031 SPACER --- 1 27270439
EV
A033 LABEL (PT) 1 29363379-1
EV
A037 BUSHING S-RELIEF #2271 1 27300750
!
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
