Onkyo HT-R508

4/62 PAGE
EV
P6602A P RIVET JB-407A-C 8 880052
EV
F901 FUSE 4A-SE-EAK FUSE 1 252077GR
!
EV
F901 or FUSE 4A-SE-TL250V (1) 252277GR
!
EV
F901C LABEL T4AL250V 1 29361732A
!
EV
F6901 FUSE 10A-UL/T-233 1 252330GR
!
EV
F6901 or FUSE 10A-T/UL-ST2 (1) 252333GR
!
EV
F6902 FUSE 10A-UL/T-233 1 252330GR
!
EV
F6902 or FUSE 10A-T/UL-ST2 (1) 252333GR
!
EV
U01 AMPLIFIER PC board ass'y NAAF-8779-2R 1 1B176579-2R
EV
U02 TRANS. SEC. TERMINAL PC board ass'y NAPS-8780-2R 1 1B176580-2R
EV
U03 THERMAL SENSOR PC board ass'y NAETC-8781-2R 1 --- NSP
EV
U04 HOLDER PC board NAETC-8782-2C 1 --- NSP
EV
U05 DISPLAY PC board ass'y NADIS-9148-1R 1 1B176548-1R
EV
U06 SWITCH PC board ass'y NADIS-9149-1R 1 1B176549-1R
EV
U07 POWER SUPPLY PC board ass'y NAPS-9150-1R 1 1B176550-1R
EV
U08 TRANS. SEC. TERMINAL PC board ass'y NAPS-9151-1R 1 1B176551-1R
EV
U09 HEADPHONE JACK PC board ass'y NAETC-9153-1R 1 --- NSP
EV
U10 HOLDER PC board NAETC-9159-1R 1 --- NSP
EV
U11 DSP PC board ass'y NADG-9177-1H 1 1B176577-1H
EV
U12 VIDEO & SPEAKER TERMINAL PC board ass'y NAVD-9178-1H 1 1B176578-1H
EV
U14 HDMI PC board ass'y NAHDM-9199-1B 1 1B176599-1B
EV
U15 TUNER UNIT ENG07505QFEU 1 240158
EV
U15 TUNER UNIT FAE485-E11EU (1) 240154
HT-R508
PC BOARD PARTS LIS
T
PCB1
U01 AMPLIFIER PC BOARD (NAAF-8779-2R)
PCB1
U02 TRANS. SEC. TERMINAL PC BOARD (NAPS-8780-2R)
PCB1
U03 THERMAL SENSOR PC BOARD (NAETC-8781-2R)
PCB1
