TX-SR604/604E/8460
VOUT2 feedback inputInVOUT2-FB67
VOUT2 signal outputOutVOUT268
VOUT1 signal outputOutVOUT169
VOUT3 signal outputOutVOUT366
VOUT3 feedback inputInVOUT3-FB65
I
2
C bus clock inputInSCL70
I
2
C bus data inputInSDA64
YOUT2 signal outputOutYOUT259
YOUT1 signal outputOutYOUT160
5.0V power supplyPower supplyVCC361
VOUT4 feedback inputInVOUT4-FB62
VOUT4 signal outputOutVOUT463
DescriptionTypePin namePin No.
YOUT2 feedback inputInYOUT2-FB58
YOUT3 signal outputOutYOUT357
YOUT3 feedback inputInYOUT3-FB56
YOUT4 signal outputOutYOUT455
YOUT4 feedback inputInYOUT4-FB54
GroundGroundGND353
COUT1 signal outputOutCOUT152
COUT2 signal outputOutCOUT251
COUT3 signal outputOutCOUT350
5.0V power supplyPower supplyVCC249
COUT4 signal outputOutCOUT448
CYOUT2 signal outputOutCYOUT247
CYOUT2 feedback inputInCYOUT2-FB46
CYOUT3 signal outputOutCYOUT345
CYOUT3 feedback inputInCYOUT3-FB44
GroundGroundGND243
PBOUT1 signal outputOutPBOUT142
PBOUT2 signal outputOutPBOUT241
General output 2OutO240
PROUT1 signal outputOutPROUT139
General output 1OutO138
PROUT2 signal outputOutPROUT237
Mute control pinInMUTE36
IC BLOCK DIAGRAM AND
Q4002: AN15881A (Video SW for TV with Multi-signal 14 Inputs and 4 Outputs)
TERMINAL DESCRIPTION (2/3)
TERMINAL DESCRIPTIONS -9
