1/55 PAGE
HT-R640
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
(B) : Black model <DD>: HT-R640 USA model
(S) : Silver model
<PP>: HT-R640 European model
EXPLODED VIEW PARTS LIS
REF. NO. NAME DESCRIPTION Q'TY PART NO(SN) REMARKS
A001 F BRACKET . 1 27111452A <DD>
A001 F
BRACKET
.
1
27111454A
<PP>
A002 SCREW 3TTB+8B(3CM)SR 27 801637
A013 WIRE TIE BSK-1 7 260208
A015 CHASSIS . 1 --- NSP
A016 SCREW 3TTB+8B(CU)SR 9 801618
A017 WIRE TIE BINDER(CLAMPER)UL 2 260258
A018 HOLDER KGLS-22S 1 27190369
A020 HOLDER KGLS-16RT 2 27190511
A021 HOLDER KGPS-16RF 4 27190991
A022 HOLDER KGLS-10RT 1 27190428A
A028 CLIP CS-1U 1 27255004
A030 SCREW 4TTC+8C(3BC) 4 830440089GR
A031 SPACER . 1 27270439
A033 LABEL (PT) 1 29363379-1
A035 HOLDER KGLS-14RT 1 27190524
A036 SCREW 3TTB+8B(CU) 1 801612
A037 BUSHING S-RELIEF #2271 1 27300750
!
A040 HEAT SINK . 1 27160589
A041 RETAINER (HL) 1 27142023
A042 RETAINER (HR) 1 27142024
A044 TAPE TAPE(CLOTH-8U) 1 29110082
A045 HOLDER KGLS-5RT 2 27191156
A049 SCREW 3SMS8W.SW+14B(CU) 14 801634
A050 IB CUSHION W15*3t TAPE 1 28141585
A051 TAPE TAPE(CLOTH-16U) 1 29110083
A052 CUSHION . 1 28141697
A053 CUSHION . 1 28141701
A055 FACET (VOL) 1 28200016
A060 COVER (B) 1 28184972 <DD>
A060 COVER
(S)
1
28184973
<PP>
A061 SCREW 3TTB+8B(3BC) 6 838430088GR <DD>>
A061 SCREW
3TTB+8B(3CM)SR
6
801637
<PP>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PAR
NUMBER SPECIFIED.
