ADJUSTMENT PROCEDURE-2
IDLING CURRENT ADJUSTMENT
<Fig-1>
HT-R640
U15
AMPLIFIER PC BOARD
(NAAF-8911)
R6042P6082
ID+
ID-
Trimming
resistor
Test
point
R
R6041P6081
ID+
ID-
Trimming
resistor
Test
point
L
R6040P6080
ID+
ID-
Trimming
resistor
Test
point
C
R6044P6084
ID+
ID-
Trimming
resistor
Test
point
SR
R6043P6083
ID+
ID-
Trimming
resistor
Test
point
SL
