TX-SR604/604E/8460
IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS -11
1
2
3
4
8
7
6
5
Vcc
WP
SCL
SDA
A0
A1
A2
GND
2k Bit EEPROM Array
8bit
8bit
8bit
Address
Decorder
Slave word
address register
Data
register
Control circuit
START STOP
ACK
High-voltage
generation circuit
Power voltage
detection
Q8506,Q8606: BR24L02FV-W(256X8 bit EEPROM)
Terminal
Vcc
GND
A0,A1,A2
SCL
SDA
WP
I/O
-
-
I
I
I/O
I
Function
Apply a power source.
Ground terminal
Slave address setting terminal
Serial clock input
Slave and word address.
Serial data input and output
Write protect terminal
BLOCK DIAGRAM AND PIN CONFIGURATION
TERMINAL DESCRIPTION
