Onkyo HT-R640 Service Manual

9/55 PAGE
S7156 PUSH SW NPS-111-S681 1 25035718T
S7158 PUSH SW NPS-111-S681 1 25035718T
S7160 PUSH SW NPS-111-S681 1 25035718T
S7162 PUSH SW NPS-111-S681 1 25035718T
S7164 PUSH SW NPS-111-S681 1 25035718T
S7166 PUSH SW NPS-111-S681 1 25035718T
E7201 TRM NTM-1P233(M1969) 1 25060302
E7301 RETAINER (S) 1 27141931
E7601 TRM(SCREW) NEJITANSI M3 1 25065425
E901 TRM(SCREW) NEJITANSI M3 1 25065425
U12 DSP PC BOARD
(
NADG-8816-1C/1D
)
U13 XM PC BOARD
(
NADG-8817-1C
)
U14
V
IDEO PC BOARD
(
NAVD-8819-1C/1D
)
CIRCUIT NO
.
NAME DESCRIPTIO
N
Q'T
Y
PART NO
(
SN
)
REMARK
S
U131 PHT CP GP1FAV51RKF5 1 24120129
U131 or PHT CP JSR1165-001recieving ( 1) 24120143
U132 PHT CP GP1FAV51RKF5 1 24120129
U132 or PHT CP JSR1165-001recieving ( 1) 24120143
U133 PHT CP GP1FAV51RKF5 1 24120129
U133 or PHT CP JSR1165-001recieving ( 1) 24120143
U134 PHT CP GP1FAV51TKBF 1 24120132
U134 or PHT CP JST1165-001transmitting ( 1) 24120142
Q131 IC 74HCU04F 1 222740046R2
Q151 IC TC74VHC541FT(EKJ) 1 22274541E1R2TO
Q151 or IC SN74AHC541PWR ( 1) 22274541IR2TI
Q151 or IC TC74VHC541FT ( 1) 22274541ER2TO
Q152 IC TC74VHCT08AFT（EKJ) 1 22274008G1R2TO
Q152 or IC TC74VHCT08AFT ( 1) 22274008GR2TO
Q153 IC TC74VHCT08AFT（EKJ) 1 22274008G1R2TO
Q153 or IC TC74VHCT08AFT ( 1) 22274008GR2TO
Q154 IC TC74VHC541FT(EKJ) 1 22274541E1R2TO
Q154 or IC SN74AHC541PWR ( 1) 22274541IR2TI
Q154 or IC TC74VHC541FT ( 1) 22274541ER2TO
Q161 TR KRC104S 1 2216210R2
Q161 or TR RN1404 ( 1) 2214490R2
Q162 TR KRC104S 1 2216210R2
Q162 or TR RN1404 ( 1) 2214490R2
Q163 TR KRA102S 1 2216220R2
Q163 or TR RN2402 ( 1) 2214530R2
Q164 TR KRA102S 1 2216220R2
Q164 or TR RN2402 ( 1) 2214530R2
Q171 IC TC7WU04FU(TE12L_F) 1 22240935R2
Q181 IC TC74VHC157FT 1 22274157ER2TO
Q2001 IC F2602E-01 1 22242266R2
<DD>
Q2002 IC AK4384ET 1 22242280R2
<DD>
Q2003 IC NE5532APSR 1 22242283R2
<DD>
Q2004 IC TA48033AF(TE16L_NQ) 1 22278033DR2TO
<DD>
Q2004 or IC BA33BC0FP ( 1) 22278033DR2RH
<DD>
Q2004 or IC NJM2391DL1-33 ( 1) 22278033DR2JR
<DD>
