Onkyo HT-R695 User Manual

10
> Specifications > Settings > Listening Modes > Playback Function > Basic Manual
Troubleshooting | Appendix
■ 2� Crossover
Setting Item Default Value Setting Details
Front 100Hz Select the crossover frequency from "40Hz" to
"200Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
•
If "Configuration" - "Subwoofer" is set to "No",
"Front" will be fixed to "Full Band" and the low
pitched range of the other channels will be
output from the front speakers. Refer to the
instruction manual of your speakers to make the
setting.
Center 100Hz Select the crossover frequency from "40Hz" to
"200Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
•
"Full Band" can be selected only when "Front" is
set to "Full Band".
•
If an item cannot be selected even though
connection is correct, check that the settings in
"Configuration" - "Speaker Channels" matches
the number of connected channels.
Height 180Hz Select the crossover frequency from "40Hz" to
"200Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
•
"Full Band" can be selected only when "Front" is
set to "Full Band".
•
If an item cannot be selected even though
connection is correct, check that the settings in
"Configuration" - "Speaker Channels" matches
the number of connected channels.
Setting Item Default Value Setting Details
Surround 100Hz Select the crossover frequency from "40Hz" to
"200Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
•
"Full Band" can be selected only when "Front" is
set to "Full Band".
•
If an item cannot be selected even though
connection is correct, check that the settings in
"Configuration" - "Speaker Channels" matches
the number of connected channels.
Surround Back (100Hz) Select the crossover frequency from "40Hz" to
"200Hz" to start outputting frequencies for each
channel.
"Full Band": Full band will be output.
•
"Full Band" can be selected only when
"Surround" is set to "Full Band".
•
If an item cannot be selected even though
connection is correct, check that the settings in
"Configuration" - "Speaker Channels" matches
the number of connected channels.
LPF of LFE 120Hz Set the low-pass filter for LFE (low-frequency
effect) signals in order to pass lower frequency
signals than the set value and thus cancel
unwanted noises. The low-pass filter will be
effective only on sources with LFE channel.
The value from "80Hz" to "120Hz" can be set.
"Off": Do not use this function
Double Bass (On) This can be selected only when "Configuration"
- "Subwoofer" is set to "Yes" and "Front" is set to
"Full Band".
Boost bass output by feeding bass sounds from
the front left and right, and center speakers to the
subwoofer.
"On": Bass output will be boosted
"Off": Bass output will not be boosted
•
The setting will not automatically be configured
even if you performed AccuEQ Room
Calibration.
