14. You can adjust the sound quality of the front speakers.
Press the TONE button (above) repeatedly to select the
item to adjust from "Bass" and "Treble", and turn the
TONE dial (below) to adjust.
15. PHONES jack: Headphones with a standard plug
(Ø1/4"/6.3 mm) are connected.
16. Input selector buttons: Switches the input to be played.
17. SETUP MIC jack: The supplied speaker setup
microphone is connected.
18. AUX INPUT AUDIO/HDMI jack: Connect a video
camera, etc., using a stereo mini plug cable (Ø1/8"/
3.5 mm) or a HDMI cable.
Display
1. Speaker/Channel display: Displays the output channel that
corresponds to the selected listening mode.
2. Lights in the following conditions.
Ë: When headphones are connected.
Z2: When ZONE 2 is on.
: When connected by BLUETOOTH.
: When connected by Wi-Fi.
NET: When "NET" is selected with the input selector and the unit is
connected to the network. It will flash if the connection to the network is
not correct.
USB: When "NET" is selected with the input selector and the unit is
connected by USB and the USB device is selected. Flashes if the USB
is not properly connected.
HDMI: When HDMI signals are input and the HDMI input is selected.
DIGITAL: When digital signals are input and the digital input is
selected.
3. Lights according to the type of input digital audio signals and the
listening mode.
4. Lights in the following conditions.
RDS (European models): Receiving RDS broadcasting.
TUNED: Receiving AM/FM radio.
FM ST: Receiving FM stereo.
SLEEP: When the sleep timer is set. (*)
AUTO STBY: Auto Standby is on. (*)
5. Flashes when muting is on.
6. Displays various information of the input signals. Characters that
cannot be displayed on this unit are replaced with asterisks ( ＊ ).
0 When playing back software which has been encoded in Dolby
Digital, Dolby Digital Plus and Dolby TrueHD, sometimes you may



see a brief message which will read
"DialogNorm: X dB" (X being a numeric
value). For example, if you see the
following message: "DialogNorm:+4 dB",
to keep the overall output level at THX
calibrated loudness, just turn down the
volume control by 4 dB.
7. This may light when performing operations
with the "NET" input selector.
(*)You can find details in the Advanced Manual.
SN29402830_HT-R997_BAS_En_1703XX.book 4 ページ ２０１７年３月１７日 金曜日 午前９時１８分

Onkyo HT-R997 Specifications

General

Audio output channels	7.1 channels
Audio formats supported	AIFF, ALAC, FLAC, WAV
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
AM band range	530 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	580 W
Subwoofer frequency range	20 - 100 Hz
Center speaker sensitivity	83 dB
Satellite speaker sensitivity	81 dB
Package weight	63000 g
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
HDMI in	7
Component video (YPbPr/YCbCr) in	2
Disc types supported	No
Optical disc player type	Not included

Weight and Dimensions

Main unit weight	10000 g
Subwoofer weight	15500 g
Satellite speaker weight	3500 g
Main unit dimensions (WxDxH)	435 x 378 x 173.5 mm
Subwoofer dimensions (WxDxH)	380 x 429 x 444 mm
Front speaker dimensions (WxDxH)	158 x 199 x 433 mm
Center speaker dimensions (WxDxH)	433 x 199 x 158 mm
Satellite speaker dimensions (WxDxH)	200 x 169 x 275 mm
