Onkyo HT-RC160 Service Manual

4/81 PAGE
P901 AC CORD AS-UC-2 1 253368AYUN !
P901 or AC CORD AS-UC-2 ( 1) 253368BLTK !
[CHASSIS SCREW]
A001 CHASSIS TX-SR507 1 27100533B
A003 BOTTOM LEG --- 4 27175432C
A004 CUSHION (BUTYL) 4 28141748
A005 CUSHION --- 4 28141664
A007 SCREW 3TTB+8B(3CM)SR 4 801637
A009 HOLDER KGLS-8RT 2 27190503A
A010 HOLDER KGPS-8RF 2 27191044
A011 HOLDER KGLS-10RT 1 27190428A
A013 HOLDER KGPS-14RF 2 27190802
A017 HOLDER KGLS-16S 1 27190607
A019 HOLDER KGPS-16RF 1 27190991
A021 HOLDER KGLS-22S 2 27190369
A023 HOLDER KGLS-22S 1 27190369
A025 SCREW 4TTC+8C(3BC) 4 830440089GR
A027 SPACER --- 1 27270439
A030 HEAT SINK 251 1 27160630
A032 RETAINER (HL) 1 27142138A
A034 RETAINER (HR) 1 27142139A
A036 SCREW 3TTB+8B(3CM)SR 4 801637
A038 SCREW 3TTB+8B(3CM)SR 2 801637
A040 SCREW 3TTB+8B(3CM)SR 4 801637
A042 SCREW 3TTB+8B(3CM)SR 2 801637
A044 HOLDER KGLS-8RT 1 27190503A
A050 SCREW 3SMS8W.SW+14B(CU) 14 801634
A054 SCREW 3TTB+8B(3CM)SR 1 801637
A056 BUSHING S-RELIEF #2271 1 27300750
A058 LABEL (PT) 1 29363379-1 *1
A060 WIRE TIE BINDER(CLAMPER)UL 2 260258
A062 WIRE TIE BSK-1 3 260208
A066 RETAINER (B) 1 27142141
A068 SCREW 3TTB+8B(3CM)SR 3 801637
A069 SCREW 3TTB+8B(3BC) 1 838430088GR
A071 LABEL (SP)570 1 29390690
A101 REAR PANEL HTRC160DC 1 27124062
