Onkyo HT-RC160 Service Manual

5/81 PAGE
A102 CUSHION --- 2 28141799
A103 SCREW 3P+6FN(3BC) 8 82143006GR
A104 CUSHION (BUTYL) 1 28141748
A105 SCREW 3TTB+8B(3BC) 29 838430088GR
[CABINET]
A201 F PANEL HTRC160(B)MDC 1 27213296
N
A202 CLEAR PLT (AS)507/607D 1 28192257
N
A207 BADGE BADGE 1 28135244
A211 F BRACKET (B) 1 27111530C
N
A215 KNOB (SEL) 1 28326665
A217 KNOB (STNBY) 1 28326663
A219 KNOB (CUR) 1 28326664A
A221 IB CUSHION W15*3t TAPE 1 28141585
A223 SCREW 2.6TTB+8B(3BC) 22 838426088GR
A250 B PLATE ---(B) 1 28133428
A254 WIRE TIE BSK-1 8 260208
A255 SCREW 3TTB+8B(3CM)SR 5 801637
A256 SCREW 3TTB+8B(3CM)SR 1 801637
A260 SCREW 3TTB+8B(3BC) 3 838430088GR
A262 TAPE TAPE(CLOTH-16U) 1 29110083
A263 TAPE TAPE(CLOTH-8U) 1 29110082
A264 CUSHION --- 3 28141681
A267 SPACER SPACER 8X3X0.188ﾎｼｭｳ 1 27270147
A321 KNOB (VOL)AS 1 28326773
N
A340 COVER (B) (Bent) 1 28210034
A340 COVER (B) (Not Bent) 1 28210034Z
A342 SCREW 3TTB+8B(3BC) 7 838430088GR
A360 LABEL (COVER) 1 29390767
A362 LABEL HOOKUP-ONKYO 1 29363194
A380 LABEL (POP)HTS7200US 1 29390955A
N
*2
[TUNER UNIT]
U001
Input selector/Volume/Power amp. pc board AS
BAAF-0014-1D * 1 1B232514-1D N
U0011
Trans 2nd terminal pc board AS
BAPS-0015-1D 1 1B232515-1D
N
U0012
Trans 2nd terminal pc board AS
BAPS-0016-1D 1 1B232516-1D
N
U0013
Thermal sensor pc board AS
BAETC-0017-1D 1 1B232517-1D
N
U0014
Holder pc board AS
BAETC-0018-1D 1 1B232518-1D
N
U0015
Holder pc board AS
BAETC-0019-1D 1 1B232519-1D
N
