Typical Single-Supply Applications (V
+
= 5.0 V
DC
)
Non-Inverting DC Gain (0V Input = 0V Output)
DS009299-5
*
R not needed due to temperature independent I
IN
DC Summing Amplifier
(V
IN’S
0V
DC
and V
O
V
DC
)
DS009299-6
Where: V
0
=V
1
+V
2
−V
3
−V
4
(V
1
+V
2
)(V
3
+V
4
) to keep V
O
>
0V
DC
Power Amplifier
DS009299-7
V
0
=0V
DC
for V
IN
=0V
DC
A
V
=10
LM124/LM224/LM324/LM2902
www.national.com9
