EXPLODED
A06 POWER SWITCH ROCKER 5A AC 250V TV-5 1 MSW0080040010 ! <MGT>
EXPLODED
A06 POWER SWITCH ROCKER 5A AC 250V TV-5 1 MSW0080040010 ! <MPT>
EXPLODED
F902, F903 FUSE 4A / 250V SLOW WALT 2 KSA0204000011 ! <MDD>
EXPLODED
F902, F903 FUSE 4A / 250V SLOW WALT 2 KSA0204000011 ! <MDC>
EXPLODED
F902, F903 FUSE 4A / 250V SLOW WALT 2 KSA0204000011 ! <MDT>
EXPLODED
F902, F903 FUSE 4A / 250V SLOW 5ST 2 KSA0204000020 ! <MPA>
EXPLODED
F902, F903 FUSE 4A / 250V SLOW 5ST 2 KSA0204000020 ! <MGT>
EXPLODED
F902, F903 FUSE 4A / 250V SLOW 5ST 2 KSA0204000020 ! <MPT>
EXPLODED
U01 MAIN PC BOARD ASS'Y MAIN PC BOARD ASS'Y 1 APE4012115001
EXPLODED
<Note>
EXPLODED
U01 : MAIN PC BOARD ASS'Y = PCB BRACKET + HEAT SINK + ALL PARTS FOR MAIN PC BOARD
EXPLODED
U02 INPUT PC BOARD ASS'Y INPUT PC BOARD ASS'Y 1 APE4012125001
EXPLODED
<Note>
EXPLODED
U02 : INPUT PC BOARD ASS'Y = INPUT PC BOARD with RCA JACK + CORD ASS'Y
EXPLODED
U03 VR / LED PC BOARD ASS'Y VR / LED PC BOARD ASS'Y 1 APE4012135001
EXPLODED
<Note>
EXPLODED
U03 : VR/ LED PC BOARD ASS'Y = VR / LED PC BOARD with VR / LED / CORD ASS'Y etc.
EXPLODED
SKF-420F (B) : FRONT SPEAKERS L / R
EXPLODED
SP10 COMPLETE UNIT "SKF-420F (B) L" 1 ANM8S670BBM10 (B)
EXPLODED
SP11 BACK LABEL (L) --- 1 YLB810004FL10 (B)
EXPLODED
SP12 COMPLETE UNIT "SKF-420F (B) R" 1 ANM8S670BBM11 (B)
EXPLODED
SP13 BACK LABEL (R) --- 1 YLB810004FR10 (B)
EXPLODED
SKF-420F (S) : FRONT SPEAKERS L / R
EXPLODED
SP10 COMPLETE UNIT "SKF-420F (S) L" 1 ANM8S670SBM10 (S)
EXPLODED
SP11 BACK LABEL (L) --- 1 YLB810004FL10 (S)
EXPLODED
SP12 COMPLETE UNIT "SKF-420F (S) R" 1 ANM8S670SBM11 (S)
EXPLODED
SP13 BACK LABEL (R) --- 1 YLB810004FR10 (S)
EXPLODED
SKC-420C (B) : CENTER SPEAKER
EXPLODED
SP14 COMPLETE UNIT "SKC-420C (B)" 1 ANC8S670BBM10 (B)
EXPLODED
SP15 BACK LABEL --- 1 YLB810004C010 (B)
EXPLODED
SKC-420C (S) : CENTER SPEAKER
EXPLODED
SP14 COMPLETE UNIT "SKC-420C (S)" 1 ANC8S670SBM10 (S)
EXPLODED
SP15 BACK LABEL --- 1 YLB810004C010 (S)
EXPLODED
SKM-420S (B) : SURROUND SPEAKERS L / R
EXPLODED
SP16 COMPLETE UNIT "SKM-420S (B) L" 1 ANU8S670BBM10 (B)
EXPLODED
SP17 BACK LABEL (L) --- 1 YLB810004SL10 (B)
EXPLODED
SP18 COMPLETE UNIT "SKM-420S (B) R" 1 ANU8S670BBM11 (B)
EXPLODED
SP19 BACK LABEL (R) --- 1 YLB810004SR10 (B)
EXPLODED
SKM-420S (S) : SURROUND SPEAKERS L / R
EXPLODED
SP16 COMPLETE UNIT "SKM-420S (S) L" 1 ANU8S670SBM10 (S)
EXPLODED
SP17 BACK LABEL (L) --- 1 YLB810004SL10 (S)
EXPLODED
SP18 COMPLETE UNIT "SKM-420S (S) R" 1 ANU8S670SBM11 (S)
EXPLODED
SP19 BACK LABEL (R) --- 1 YLB810004SR10 (S)
HTP-420
PRINTED CIRCUIT BOARD PARTS LIS
T
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) MARK
PWB
IC501 POWER IC 15PIN TDA7293 1 RHI007293-0001
PWB
DB901 DIODE RS402L 4A 100V 1 RHD2040100011
!
