HTP-420
EXPLODED VIEW PARTS LIS
T
<Notes>
(B) : Black model
(S) : Silver model
<MDD> : American model
<MDC> : Canadian model
<MDT> : Asian model (120V)
<MPA> : Australian model
<MGT> : Asian model (220-230V)
<MPT> : Asian model (230-240V)
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) MARK
EXPLODED
SKW-420 (B) / (S) : POWERED SUBWOOFER
EXPLODED
SP01 CABINET ASS'Y (B) Black 1 ANW8W670BBM10 <MDD>
EXPLODED
SP01 CABINET ASS'Y (B) Black 1 ANW8W670BBM10 <MDC>
EXPLODED
SP01 CABINET ASS'Y (B) Black 1 ANW8W670BBM30 <MPA>
EXPLODED
SP01 CABINET ASS'Y (S) Silver 1 ANW8W670SBM10 <MDD>
EXPLODED
SP01 CABINET ASS'Y (S) Silver 1 ANW8W670SBM10 <MDC>
EXPLODED
SP01 CABINET ASS'Y (S) Silver 1 ANW8W670SBM10 <MDT>
EXPLODED
SP01 CABINET ASS'Y (S) Silver 1 ANW8W670SBM30 <MPA>
EXPLODED
SP01 CABINET ASS'Y (S) Silver 1 ANW8W670SBM40 <MGT>
EXPLODED
SP01 CABINET ASS'Y (S) Silver 1 ANW8W670SBM60 <MPT>
EXPLODED
SP02 FOOT D87.5 x D37.5 x H50 HIPS BLK 4 BPE8000040001
EXPLODED
SP03 BOTTOM BOARD F2905-GW 1 ANF860002BM10 (B)
EXPLODED
SP03 BOTTOM BOARD F2905-GW 1 ANF860003BM10 (S)
EXPLODED
SP04 FRONT PLATE SKW-420 / ONKYO NAME PLATE 1 BPL8001470001
EXPLODED
SP05 WOOD SCREW 8 x 4 x L75 (FOR FOOT) 8 NST8550514750
EXPLODED
SP06 WOOD SCREW 4STT+20A (FOR AMPLIFIER / SP) 18 837440204
EXPLODED
SP08 WOOFER SPEAKER 20cm 4ohm 50W 1 W20178A
EXPLODED
A01 REAR PANEL "SKW-420" SPCC 190 x 120 x T2.0mm 1 GSE4001750001 <MDD>
EXPLODED
A01 REAR PANEL "SKW-420" SPCC 190 x 120 x T2.0mm 1 GSE4001750001 <MDC>
EXPLODED
A01 REAR PANEL "SKW-420" SPCC 190 x 120 x T2.0mm 1 GSE4001750001 <MDT>
EXPLODED
A01 REAR PANEL "SKW-420" SPCC 190 x 120 x T2.0mm 1 GSE4001750004 <MPA>
EXPLODED
A01 REAR PANEL "SKW-420" SPCC 190 x 120 x T2.0mm 1 GSE4001750003 <MGT>
EXPLODED
A01 REAR PANEL "SKW-420" SPCC 190 x 120 x T2.0mm 1 GSE4001750004 <MPT>
EXPLODED
A02 AC CORD LINE CORD 2P 1800mm BLK POLARIZE 1 VPA0040120010 ! <MDD>
EXPLODED
A02 AC CORD LINE CORD 2P 1800mm BLK POLARIZE 1 VPA0040120010 ! <MDC>
EXPLODED
A02 AC CORD LINE CORD 2P 1800mm BLK POLARIZE 1 VPA0040120010 ! <MDT>
EXPLODED
A02 AC CORD LINE CORD 2P 1980mm BLK SAA 1 VPE0010140010 ! <MPA>
EXPLODED
A02 AC CORD LINE CORD 2P 1980mm BLK VDE 1 VPE003012-0020 ! <MGT>
EXPLODED
A02 AC CORD LINE CORD 2P 1980mm BLK VDE 1 VPE003012-0020 ! <MPT>
EXPLODED
A03 BUSHING AC LINE BUSHING 1 DBU001002-0011
!
EXPLODED
A04 POWER TRANSFORMER AC120V / 60Hz 100W 1 TTI1120010120 ! <MDD>
EXPLODED
A04 POWER TRANSFORMER AC120V / 60Hz 100W 1 TTI1120010120 ! <MDC>
EXPLODED
A04 POWER TRANSFORMER AC120V / 60Hz 100W 1 TTI1120010120 ! <MDT>
EXPLODED
A04 POWER TRANSFORMER AC230 / 240V / 50Hz 100W 1 TTI4234100010 ! <MPA>
EXPLODED
A04 POWER TRANSFORMER AC220 / 230V / 50Hz 100W 1 TTI4223100010 ! <MGT>
EXPLODED
A04 POWER TRANSFORMER AC230 / 240V / 50Hz 100W 1 TTI4234100010 ! <MPT>
EXPLODED
A05 SCREW M4.0 x P0.7 x L25mm (FOR TRANS) 4 HSD1431033250
EXPLODED
A06 POWER SWITCH ROCKER 5A AC 250V TV-5 1 MSW0080040010 ! <MPA>
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
