Onkyo HTR-280(B) - Page 59

U004
4
PWB
(
HP-Jack
)
BAETC-0377-1C 1 1B2475377-1
C
N
CIRCUIT PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D7002 ZENER D UDZS8.2B 1 224550820R2
D7033 ZENER D UDZS3.9B 1 224550390R2
D7151 LED SLI-343URC-TE7 1 225449T
D7152 LED SLI-343Y8C-TE7 1 225490T
N
D9011 DIODE D5SBA20 1 22380130F <B CMDC>
D9014 C-DIODE KDS4148U 1
NSP
D9014 or C-DIODE 1SS352 ( 1)
NSP
D9014 or C-DIODE MA2J111 ( 1)
NSP
D9015 C-DIODE KDS4148U 1
NSP
D9015 or C-DIODE 1SS352 ( 1)
NSP
D9015 or C-DIODE MA2J111 ( 1)
NSP
D9016 ZENER D UDZS6.2B 1 224550620R2 <B CMDC>
D9023 C-DIODE KDS4148U 1
NSP
D9023 or C-DIODE 1SS352 ( 1)
NSP
D9023 or C-DIODE MA2J111 ( 1)
NSP
D9025 C-DIODE KDS4148U 1
NSP
D9025 or C-DIODE 1SS352 ( 1)
NSP
D9025 or C-DIODE MA2J111 ( 1)
NSP
D9032 C-DIODE KDS4148U 1
NSP
D9032 or C-DIODE 1SS352 ( 1)
NSP
D9032 or C-DIODE MA2J111 ( 1)
NSP
D911 C-DIODE KDS4148U 1
NSP
D911 or C-DIODE 1SS352 ( 1)
NSP
D911 or C-DIODE MA2J111 ( 1)
NSP
D912 C-DIODE KDS4148U 1
NSP
D912 or C-DIODE 1SS352 ( 1)
NSP
D912 or C-DIODE MA2J111 ( 1)
NSP
D921 C-DIODE KDS4148U 1
NSP
D921 or C-DIODE 1SS352 ( 1)
NSP
D921 or C-DIODE MA2J111 ( 1)
NSP
D922 C-DIODE KDS4148U 1
NSP
D922 or C-DIODE 1SS352 ( 1)
NSP
D922 or C-DIODE MA2J111 ( 1)
NSP
D923 C-DIODE KDS4148U 1
NSP
D923 or C-DIODE 1SS352 ( 1)
NSP
D923 or C-DIODE MA2J111 ( 1)
NSP
D924 C-DIODE KDS4148U 1
NSP
D924 or C-DIODE 1SS352 ( 1)
NSP
D924 or C-DIODE MA2J111 ( 1)
NSP
D925 C-DIODE KDS4148U 1
NSP
