Onkyo HTR-280(B)

R714 C-CARBON R RN72K1J-103JE 1
NSP
R715 C-CARBON R RN72K1J-103JE 1
NSP
R716 C-CARBON R RN72K1J-470JE 1
NSP
R721 C-CARBON R RN72K1J-103JE 1
NSP
R723 C-CARBON R RN72K1J-101JE 1
NSP
R724 C-CARBON R RN72K1J-101JE 1
NSP
R725 C-CARBON R RN72K1J-221JE 1
NSP
R726 C-CARBON R RN72K1J-273JE 1
NSP
R801 C-CARBON R RN72K1J-000JE 1
NSP
R807 C-CARBON R RN72K1J-000JE 1
NSP
<B CMDC>
R811 C-CARBON R RN72K1J-000JE 1
NSP
<B CMDC>
R813 C-CARBON R RN72K1J-000JE 1
NSP
<B CMDC>
R823 C-CARBON R RN72K1J-000JE 1
NSP
<B CMDC>
R824 C-CARBON R RN72K1J-000JE 1
NSP
<B CMDC>
[SW TRM]
JL501B WIRE TRAP NPLG-3P586 1 25055624
JL502B WIRE TRAP NPLG-5P588 1 25055626
JL901B WIRE TRAP NPLG-5P588 1 25055626
P101A SOCKET NSCT-11P2104 1 25052207 <B CMDC>
P131 PIN JACK NPJ-1PDO554 1 25045772 <B CMDC>
P2001A SOCKET IMSA-9142S-24A 1 25053234
P2002B SOCKET NSCT-15P2195 1 25052298
P2081 SOCKET NNA1-01-006 1 25053357
P5501A SOCKET NSCT-7P2187 1 25052290
P5502A SOCKET NSCT-15P2195 1 25052298
P5503A SOCKET NSCT-9P2189 1 25052292
P5504A SOCKET NSCT-7P2187 1 25052290 <B CMDC>
P701A SOCKET NSCT-31P2124 1 25052227
P751A SOCKET IMSA-9618S-09A 1 25053334R2
P8001A PLUG IMSA-9111B-16 1 25056620
P8002A PLUG IMSA-9111B-24 1 25056625
[TUNER UNIT]
U131 PHT CP JSR1165-001recieving 1 24120143
U132 PHT CP JSR1165-001recieving 1 24120143
HT-R280
PC BOARD PARTS LIS
T
U004
DIS-AS
(
Displa
y
Ass
y)
U0040+U0041+U0042+U0043+U0044
BADIS-0373-1C * 1 1B247573-1C or 380c
U0040
DIS-AS
(
Dis
p
la
y
Ass
y)
BADIS-0373-1
C
1 1B2475373-1
C
U0041
PWB
(
STANDBY ke
y
/LED
)
BADIS-0374-1
C
1 Included in "REF,NO, U00
4
N
U0042
PWB
(
Video Ass
y)
BAVD-0375-1C 1 1B2475375-1
C
N
U0043
PWB
(
Power Si
pp
l
y
BAETC-0376-1C 1 1B2475376-1
C
N
