Onkyo HTR-990 - Page 20

TX-NR509/ TX-NR579/ TX-NA579/ HT-R590/ HT-R690/ HT-R990
PRINTED CIRCUIT BOARD VIEWS-1
U001
BAAF-0621
(U0010 to U0017)
A-side view
U0013
SPACER PC BOARD
BAETC-0624
U0014
WIRING
CIRCUIT PC BOARD
BAETC-0625
U0016
POWER SUPPLY
CIRCUIT PC BOARD
BAETC-0627
U0017
PART FIXTURE
PC BOARD
BAETC-0764
U0015
FFC FIXTURE
PC BOARD
BAETC-0626
U0012
THERMAL SENSOR
CIRCUIT PC BOARD
BAETC-0623
U0011 SPEAKER TERMINAL CIRCUIT PC BOARD BAETC-0622
U0010
POWER AMP/ AUDIO INPUT CIRCUIT PC BOARD
BAAF-0621
A
1
2
3
4
5
BCDEFGH
