PRINTED CIRCUIT BOARD VIEWS-2
U002
BADIS-0663
(U0020 to U0024)
A-side view
U0020
DISPLAY CIRCUIT PC BOARD
BADIS-0663
U0021
VIDEO INPUT TERMINALS CIRCUIT PC BOARD
BAVD-0664
U0022
STANDBY ETC. SWITCH
CIRCUIT PC BOARD
BAETC-0665
U0024
POWER SUPPLY CIRCUIT PC BOARD
BAPS-0667
U0023
HEADPHONES
CIRCUIT PC BOARD
BAETC-0666
