Onkyo HTR-990

4/83 PAGE
EV
U001 BAAF-0621-1H * 1 1B258521-1H N <MPP>
EV
U0010 Power Amp / Audio Input Terminals PC board ass'y BAAF-0621-1G 1 1B2585621-1G <MDC>
EV
U0010 BAAF-0621-1H 1 1B2585621-1H
N
<MPP>
EV
U0011 Center Speaker Terminal PC board ass'y BATRM-0622-1G 1 1B2585622-1G
N
<MDC>
EV
U0011 BATRM-0622-1H 1 1B2585622-1H
N
<MPP>
EV
U0012 Thermal Senser PC board ass'y BAETC-0623-1G 1 1B2585623-1G
N
<MDC>
EV
U0012 BAETC-0623-1H 1 1B2585623-1H
N
<MPP>
EV
U0013 Spacer PC board BAETC-0624-1G 1 1B2585624-1G
N
<MDC>
EV
U0013 BAETC-0624-1H 1 1B2585624-1H
N
<MPP>
EV
U0014 Terminal PC board BAETC-0625-1G 1 1B2585625-1G
N
<MDC>
EV
U0014 BAETC-0625-1H 1 1B2585625-1H
N
<MPP>
EV
U0015 FFC Fixture PC board BAETC-0626-1G 1 1B2585626-1G
N
<MDC>
EV
U0015 BAETC-0626-1H 1 1B2585626-1H
N
<MPP>
EV
U0016 Power supply PC board BAETC-0627-1G 1 1B2585627-1G
N
<MDC>
EV
U0016 BAETC-0627-1H 1 1B2585627-1H
N
<MPP>
EV
U002 U0020 + U0021 + U0022 + U0023 + U0024 BADIS-0663-1N * 1 1B258563-1N N <MDC>
EV
U002 BADIS-0663-1F * 1 1B258563-1F N <MPP>
EV
U0020 Display PC board ass'y BADIS-0663-1N 1 1B2585663-1N
N
<MDC>
EV
U0020 BADIS-0663-1F 1 1B2585663-1F
N
<MPP>
EV
U0021 Video PC board ass'y BAVD-0664-1N 1 1B2585664-1N
N
<MDC>
EV
U0021 BAVD-0664-1F 1 1B2585664-1F
N
<MPP>
EV
U0022 LED PC board ass'y BAETC-0665-1N 1 1B2585665-1N
N
<MDC>
EV
U0022 BAETC-0665-1F 1 1B2585665-1F
N
<MPP>
EV
U0023 Phone Jack PC board ass'y BAETC-0666-1N 1 1B2585666-1N
N
<MDC>
EV
U0023 BAETC-0666-1F 1 1B2585666-1F
N
<MPP>
EV
U0024 Power supply PC board ass'y BAPS-0667-1N 1 1B2585667-1N
N
<MDC>
EV
U0024 BAPS-0667-1F 1 1B2585667-1F
N
<MPP>
EV
U003 HDMI PC board ass'y BAHDM-0684-1E * 1 1B258584-1E <MDC>
EV
U003 BAHDM-0684-1E * 1 1B258584-1E <MPP>
EV
U004 U0040 + U0041 BADG-0643-1B * 1 1B258543-1B N <MDC>
EV
U004 BADG-0643-1C * 1 1B258543-1C N <MPP>
EV
U0040 Digital PC board ass'y BADG-0643-1B 1 1B2585643-1B
N
<MDC>
EV
U0040 BADG-0643-1C 1 1B2585643-1C
N
<MPP>
EV
U0041 PC IN terminal PC board ass'y BAETC-0646-1B 1 1B2585646-1B <MDC>
EV
U0041 BAETC-0646-1C 1 1B2585646-1C <MPP>
