Onkyo HTR-990

6/83 PAGE
PV
A828 INS MANUAL U2EnDe(Last.fm_Nap_Spotify) 1 29400794
N
<MPP>
PV
A830 INST SHEET WEEE 1 29355793A <MPP>
PV
A835 HANDBILL (UP-A1)US 1 29380155A <MDC>
PV
A835 HANDBILL (UP-A1)EU 1 29380156A <MPP>
PV
A840 INS MANUAL U9(2011_Prepro) 1 29400572A
PV
A842 INS MANUAL DeNlSv(HT-R990) 1 29400667
N
<MPP>
PV
A855 REMO CON RC-801M 1 24140801
PV
A856 MIC MIC-7000 1 245044
PV
A858 ANT COIL NMA-3057 1 232140
PV
A859 FM ANT AS Type W 1 292191
PV
A861 BATTERY R6/AA(UM-3) 2 3010194 <MDC, MPP>
PV
A861 or BATTERY R6/AA(UM-3) ( 2) 3010054 <MDC, MPP>
PV
A885 WRNTY CARD (ONKYO) 1 29365135 <MDC>
HT-R990
U001
PC BOARD PARTS LIS
T
U001
U001
U001 U0010 + U0011 + U0012 + U0013 + U0014 + U0015 + U0016
U001
U0010
Power Amp / Audio Input Terminals PC board a
s
BAAF-0621-1G / 1H
U001
U0011
Center Speaker Terminal PC Board ass'y BATRM-0622-1G / 1H
U001
U0012
Thermal Senser PC board ass'y BAETC-0623-1G / 1H
U001
U0013
Spacer PC board ass'y BAETC-0624-1G / 1H
U001
U0014
Terminal PC board ass'y BAETC-0625-1G / 1H
U001
U0015
FFC Fixture PC board ass'y BAETC-0626-1G / 1H
U001
U0016
Power supply PC board ass'y BAETC-0627-1G / 1H
U001
U001
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
U001
[SEMI CONDUCTOR]
U001
D4107 C-DIODE DA2J10100 1 223303R2 <MDC, MPP>
U001
D4107 or C-DIODE 1SS352 ( 1) 223234R2 <MDC, MPP>
U001
D4107 or C-DIODE 1SS355 ( 1) 223269R2 <MDC, MPP>
U001
D4107 or C-DIODE MA2J111 ( 1) 223279R2 <MDC, MPP>
U001
D4107 or C-DIODE KDS4148U ( 1) 223283R2 <MDC, MPP>
U001
D4117 C-DIODE DA2J10100 1 223303R2 <MDC, MPP>
U001
D4117 or C-DIODE 1SS352 ( 1) 223234R2 <MDC, MPP>
U001
D4117 or C-DIODE 1SS355 ( 1) 223269R2 <MDC, MPP>
U001
D4117 or C-DIODE MA2J111 ( 1) 223279R2 <MDC, MPP>
U001
D4117 or C-DIODE KDS4148U ( 1) 223283R2 <MDC, MPP>
U001
D4171 ZENER D MTZJ6.8B 1 224470682T
