Onkyo HTR-990

10/83 PAGE
U001
Q4102 TR RN1441 1 2215410R2
U001
Q4103 TR RN1441 1 2215410R2
U001
Q4104 TR RN1441 1 2215410R2
U001
Q4105 TR RN1441 1 2215410R2
U001
Q4106 TR RN1441 1 2215410R2
U001
Q4107 TR RN1441 1 2215410R2
U001
Q4108 TR RN1441 1 2215410R2 <MDC, MPP>
U001
Q4109 TR RN1441 1 2215410R2 <MDC, MPP>
U001
Q4117 TR RN1441 1 2215410R2
U001
Q4130 IC NJM4580M-D 1 22241448R2
U001
Q4170 IC 78M15HF(NJM78M15FA) 1 222780155JRC
U001
Q4170 or IC UPC78M15AHF-AZ ( 1) 222780155NEC
U001
Q4170A HEAT SINK RAD-196 1 27160545
U001
Q4170B SCREW 3P+10FN(3BC) 1 82143010GR
U001
Q4171 IC 79M15HF(NJM79M15FA) 1 222790155JRC
U001
Q4171 or IC UPC79M15HF-AZ ( 1) 222790155NEC
U001
Q4171B SCREW 3P+10FN(3BC) 1 82143010GR
U001
Q4400 IC NJM4580M-D 1 22241448R2 <MDC, MPP>
U001
Q4401 TR 2SC2235-Y(TPE6_F) 1 2211654T <MDC, MPP>
U001
[NOTICE]
U001
Q6001, Q6002, Q6003 and the surrounding parts have been changed as follows in the middle of production. Refer to SCHEMATIC-DIAGRAM-4(AMP. SECTION)
U001
Change C6120, C6121 and C6122 at the same time when Q6001 is changed.
U001
Q6001
IC STK-443-530-E 1 222148 BEFORE
U001
↓↓
U001
IC
STK-443-530N-E
1
222152
AFTER
U001
C6120 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
C6121 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
C6122 C-CERA C CC725CH1H-101J1 0 342101014R1 BEFORE
U001
↓
U001
C-CERA C CC725CH1H-101J1
1
342101014R1 AFTER
U001
Change C6123 and C6124 at the same time when Q6002 is changed.
U001
Q6002
IC STK-442-730-E 1 222150 N BEFORE
U001
↓↓
U001
IC
STK-442-730N-E
1
222153
AFTER
U001
C6123 C-CERA C CC725CH1H-561J1 0 342105614R1 BEFORE
