Onkyo LS3200 User Manual

25
En
Specifications
Audio Inputs
Audio Output
Specifications and features are subject to
change without notice.
Controller (LAP-302)
Rated Output Power
All channels: (North American)
20 watts minimum continuous
power per channel, 4 ohm loads,
2 channels driven at 1 kHz, with a
maximum total harmonic
distortion of 0.8% (FTC)
(Others)
2 ch × 20 W at 4 ohms, 1 kHz,
2 ch driven of 0.8% (IEC)
Maximum Effective Output Power
(Australian)
2 ch × 22 W at 4 ohms, 1 kHz,
2 ch driven (JEITA)
THD+N (Total Harmonic Distortion+Noise)
0.8% (Power Rated)
0.2% (1kHz, 1W)
Damping Factor 29 (1 kHz, 8 Ω)
Frequency Response
50 Hz - 20 kHz/+3 dB, –3 dB
(DIGITAL)
Speaker Impedance
4 Ω - 8 Ω
Power Supply AC 100 - 240 V, 50/60 Hz
Power Consumption
17 W
Stand-by Power Consumption
0.5 W
Dimensions (W × H × D)
187 mm × 32 mm × 120 mm
7-3/8" × 1-1/4" × 4-3/4"
Weight 0.3 kg (0.7 lbs.)
Digital Optical: 1 Coaxial: 1
Analog Stereo Input
ø 3.5 mm mini
Bluetooth Version: 2.1+EDR
Profile: A2DP GAVDP
Speaker Output SPEAKER OUT
Front Speaker (SLM-302)
Type Full Range Closed Box
Impedance 4 Ω
Maximum input power
20 W
Output sound pressure level
86 dB/W/m
Frequency Response
200 Hz - 20 kHz
Cabinet capacity 0.6 L (0.021 cubic feet)
Dimensions (W × H × D)
169 mm × 78 mm × 108 mm
6-5/8" × 4-3/8" × 5-1/4"
(incl. grille and projection)
Weight 0.7 kg (1.5 lbs.)
Drivers unit 6.5 cm (2-1/2") cone × 2
Terminal Spring type
Other Non magnetic shielding
Subwoofer (SKW-B50)
Rated Output Power (FTC)
(North American)
50 watts minimum continuous
power, 4 ohms, driven at 100 Hz with
a maximum total harmonic distortion
of 1%
Rated Output Power (IEC)
(Others)
50 watts minimum continuous
power, 4 ohms, driven at 100 Hz with
a maximum total harmonic distortion
of 1%
Play Frequency Band
40 Hz - 200 Hz
Cabinet capacity 11.5 L (0.41 cubic feet)
Dimensions (W × H × D)
261 mm × 337 mm × 269 mm
10-1/4" × 13-1/4" × 10-9/16"
Weight 5.8 kg (12.8 lbs.)
Drivers unit 16 cm (6-1/2") cone
Power Supply (North American) AC 120 V, 60 Hz
(Others) AC 220 - 240 V, 50/60 Hz
Power Consumption
15 W
Other Non magnetic shielding
Auto standby
