Onkyo LS7200 User Manual

46
> Before Start > Part Names > Install > Initial Setup > Playback
Supplementary information | Advanced Setup | Others
E
N
3. Audio Adjust
■ 1. Multiplex/Mono
■ 2. Dolby
■ 3. DTS
■ 4. LFE Level
Set the low-frequency effect (LFE) level for Dolby Digital series, DTS series, Multichannel
PCM, and DSD signals.
■ 5. Volume
Multiplex Input
Channel
Set the audio channel or language to be output when playing
multiplex audio or multilingual TV broadcasts etc.
"Main (Default Value)": Main channel only
"Sub": Sub channel only
"Main / Sub": Main and sub channels will be output at the same
time.
0 If multiplex audio is being played, "1+1" will be displayed on
the display of the main unit when on the remote controller
is pressed.
Mono Input Channel Set the input channel to use for playing any 2 ch digital source
such as Dolby Digital, or 2 ch analog/PCM source in the Mono
listening mode.
"Left": Left channel only
"Right": Right channel only
"Left + Right (Default Value)": Left and right channels
Loudness
Management
When playing Dolby TrueHD, enable the dialog normalization
function which keeps the volume of dialog at a certain level. Note
that when this setting is Off, the Late Night function that allows
you to enjoy surround at low volumes is fixed to Off when playing
Dolby Digital Plus/Dolby TrueHD.
"On (Default Value)": Use this function
"Off": Do not use this function
DTS Auto Surround When inputting DTS signals that include extended channel
information, the optimum listening mode is automatically
selected according to the extended information contained in the
input signal and the speaker configuration of this unit when
playing in the straight decoding listening mode.
"On (Default Value)": Use this function
"Off": Audio is played using the same amount of channels in the
input signal according to the speaker configuration of this unit.
LFE Level Select the low-frequency effect (LFE) level of each type of signal
from "0 dB (Default Value)" to "j ∞ dB". If the low-frequency
effect sound is too strong, select "j20dB" or "j ∞ dB".
Maximum Volume Set the maximum value to avoid too high volume. Select "Off
(Default Value)" or a value between "30" and "49".
Headphone Level Adjust the output level of the headphones. Select a value
between "j12 dB" and "i12 dB". (Default Value is "0 dB")

Onkyo LS7200 Specifications

General

Disc types supported	No
Optical disc player type	Not included
Audio decoders	DSD, DTS:X, Dolby Atmos
Audio output channels	5.0 channels
Audio Return Channel (ARC)	Yes
Signal-to-Noise Ratio (SNR)	80 dB
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	40
Bluetooth version	4.1
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.38 W
Power consumption (typical)	60 W
Subwoofer type	Active subwoofer
Subwoofer sensitivity	90 dB
Subwoofer frequency range	30 - 200 Hz
Subwoofer driver diameter (imperial)	6.2 \
Package weight	18000 g
Cables included	AC
HDMI in	4
USB version	2.0
Number of HDMI outputs	1
S-Video outputs quantity	0
Karaoke	-
Product color	Black

Weight and Dimensions

Main unit weight	4000 g
Subwoofer weight	6200 g
Main unit dimensions (WxDxH)	435 x 325.5 x 70 mm
Subwoofer dimensions (WxDxH)	261 x 269 x 338 mm
