4. Source
■ 1. IntelliVolume
Adjust the volume level difference between the devices connected to the unit. Select the
input selector to configure.
■ 2. Name Edit
Set an easy name to each input. The set name will be shown on the main unit display. Select
the input selector to configure.
0 To name a preset radio station, press TUNER on the remote controller, select FM and
select the preset number.
0 This cannot be set if the "NET", "USB" or "BLUETOOTH" input is selected.
■ Audio Select
Select the priority for input selection when multiple audio sources are connected to one input
selector. The setting can be separately set to each input selector button. Select the input
selector to configure.
0 The setting cannot be changed when "TUNER", "NET", "USB", or "BLUETOOTH" input is
selected.
IntelliVolume Select a value between "j12 dB" and "i12 dB". Set a negative
value if the volume of the target device is larger than the others
and a positive value if smaller. To check the audio, start playback
of the connected device. (Default Value is "0 dB")
Name Edit 1. Select a character or symbol with the cursors and press
ENTER.
Repeat it to input 10 or less characters.
"A/a": Switches between upper and lower cases. (Pressing
MODE on the remote controller also toggles between upper
and lower cases)
" ← " " → ": Moves the cursor to the arrow direction.
" ": Removes a character on the left of the cursor.
" ": Enters a space.
0 Pressing CLEAR on the remote controller will remove all
the input characters.
2. After inputting, select "OK" with the cursors and press
ENTER.
The input name will be saved.
Audio Select "ARC": When giving priority to input signal from ARC compatible
TV.
0 The setting can be selected only when "5. Hardware" - "HDMI"
- "Audio Return Channel" is set to "Auto" and also the "TV"
input is selected.
"HDMI": When giving priority to input signal from HDMI IN jacks
0 The setting can be selected only when the input is assigned to
the HDMI jack in the "1. Input/Output Assign" - "HDMI Input"
setting.
"OPTICAL": When giving priority to input signal from DIGITAL IN
OPTICAL jacks
0 The setting can be selected only when the input is assigned to
the OPTICAL jack in the "1. Input/Output Assign" - "Digital
Audio Input".
"Analog": To always output analog audio independently of the
input signal
0 The setting can be selected only when the input is assigned to
the AUDIO IN jack in the "1. Input/Output Assign" - "Analog
Audio Input" setting.
(Default Value: BD/DVD: HDMI, CBL/SAT: HDMI, GAME: HDMI,
STRM BOX: HDMI, CD: Analog, TV: OPTICAL)
PCM Fixed Mode Select whether to fix input signals to PCM (except multi-channel
PCM) when you have selected "HDMI", or "OPTICAL" in the
"Audio Select" setting. Set this item to "On" if noise is produced
or truncation occurs at the beginning of a track when playing
PCM sources. Select "Off (Default Value)" normally.
0 Changing "Audio Select" changes the setting to "Off".

Onkyo LS7200 Specifications

General

Disc types supported	No
Optical disc player type	Not included
Audio decoders	DSD, DTS:X, Dolby Atmos
Audio output channels	5.0 channels
Audio Return Channel (ARC)	Yes
Signal-to-Noise Ratio (SNR)	80 dB
FM band range	87.5 - 108 MHz
Supported radio bands	FM
Preset stations quantity	40
Bluetooth version	4.1
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.38 W
Power consumption (typical)	60 W
Subwoofer type	Active subwoofer
Subwoofer sensitivity	90 dB
Subwoofer frequency range	30 - 200 Hz
Subwoofer driver diameter (imperial)	6.2 \
Package weight	18000 g
Cables included	AC
HDMI in	4
USB version	2.0
Number of HDMI outputs	1
S-Video outputs quantity	0
Karaoke	-
Product color	Black

Weight and Dimensions

Main unit weight	4000 g
Subwoofer weight	6200 g
Main unit dimensions (WxDxH)	435 x 325.5 x 70 mm
Subwoofer dimensions (WxDxH)	261 x 269 x 338 mm
