Onkyo R-801A Service Manual

R-801A
PARTS LIST
CIRCUIT SECTION 1
U1 Main PC board(NAAF-7336-1B/1C/1D/1E)
REF. NO. PART NO DESCRIPTION
ICs
Q351 22241221R2
TC9164AF
Q933 222780055JRC or
78M05(NJM78M05FA)
222780055MIT or
78M05L(M5F78M05L)
222780055NEC
78M05HF(MPC78M05HF)
Q934 222780565JRC
78M56(NJM78M56FA)
Transistors
Q508,Q608 2215864 or
KTC3199-GR
2212115 or
2SC2458-GR
2213284 or
2SC1740S-R
2213285
2SC1740S-S
Q509,Q609 2216563 or
KTC1027-O
2211654 or
2SC2235-Y
2216564
KTC1027-Y
Q510,Q610 2216573 or
KTA1023-O
2211644 or
2SA965-Y
2216574
KTA1023-Y
Q781 2216185R2 or
KTA1504-GR
2214374R2
2SA1162-Y
Q782 2216175R2 or
KTC3875-GR
2213143R2 or
2SC2712-O
2213144R2 or
2SC2712-Y
2213145R2 or
2SC2712-GR
2216173R2 or
KTC3875-O
2216174R2
KTC3875-Y
Q932 2215975 or
KTA1266-GR
2211455
2SA1015-GR
Diodes
D931 22380271 or
D3SBA20
22380022 or
RBV402
22380285
RS403M
D933-D939 22380260 or
RL1N4003
22380032 or
1SR139-100
22380035
GP104003E
D934,D944 22380032
1SR139-100
D943,D944 22380260 or
RL1N4003
22380035
GP104003E
D781 223234R2 or
1SS352,Chip
223269R2
1SS355,Chip
D940 224492700R2 or
UDZ27B,Zener
224552700R2
UDZS27B,Zener
D941,D942 224490390R2 or
UDZ3.9B,Zener
224550390R2 or
UDZS3.9B,Zener
D945-D948 224490390R2 or
UDZ3.9B,Zener
224550390R2
UDZS3.9B,Zener
U1 Main PC board(NAAF-7336-1B/1C/1D/1E)
REF. NO. PART NO DESCRIPTION
Capacitors
C352,C937 354761019
100uF,35V,Elect.
C511,C611 354741009
10uF,16V,Elect.
C781 354744709
47uF,16V,Elect.
C938,C939 354781019
100uF,50V,Elect.
C942,C943 354742219
200uF,16V,Elect.
C945,C947 354741009
10uF,16V,Elect.
C933,C934 393353327
3300uF,25V,Elect.
C936 393352227
3300uF,25V,Elect.
C512,C612 374724734
ECQ-V50V-473J,Plastic film
C931,C932 374723344
ECQ-V50V-334J,Plastic film
C512,C612 374724734
ECQ-V50V-473J,Plastic film
C931,C932 374723344
ECQ-V50V-334J,Plastic film
Resistors
R521,R621 443521014
100ohm +/-5%,1/2W,Metal oxide
R932,R938 442521004
10ohm +/-5%,1/2W,Metal oxide
R936,R937 442723314
330ohm +/-5%,2W,Metal oxide
R939 442625604
56ohm +/-5%,1W,Metal oxide
R522,R622 4500027
0.22ohm +/-5%,2W,Metal plate
R523,R623 453530824
8.2ohm +/-5%,1/2W,Metal
R931 453534794
0.47ohm +/-5%,1/2W,Metal
R940 452530474
4.7ohm +/-5%,1/2W,Metal
R522,R622 4800071
RSS2WK-0.22,Cement resistor
Plugs
P101A 25055709
NPLG-13P665
P102A,P103A 25055702
NPLG-6P658
P304A,P501A 25055708
NPLG-12P664
P305 25055038
NPLG-2P29
P502A,P503A 25055804
NPLG-4P760
Sockets
JL501B,JL502B 25050269
NSCT-5P97
JL931B 25050272
NSCT-8P100
JL932B 25050268
NSCT-4P96
P701A 25052223
NSCT-27P2120
P303A 2009990697UL
NSAS-6P0972
Jacks
P301,P302 25045575 or
NPJ-4PDRW389
25045303
NPJ-4PDBL162
Retainer
E931 27141059
Retainer
Note
<PP>..........European model only
<DT>.........120V model only
<GT,GR>...220-230V model only
THE COMPONENTS IDENTIFIED BY MARK ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
