Onkyo R-801A Service Manual

R-801A
PARTS LIST
CIRCUIT SECTION 2
U2 Acoustic PC board(NAAF-7337-1B/1C/1D/1E)
REF. NO. PART NO DESCRIPTION
ICs
Q361,Q461 22241383R2 or
NJM4565M-D
22240489R1NE
MPC4570G2-T1(MST)
Q381 22240981R2
TC9162AF
Transistors
Q362,Q462 2215510R2
RN1443
Q382 2216220R2 or
KRA102S
2214530R2
RN2402
Capacitors
C361,C367 354742209
22uF,16V,Elect.
C369,C385 354780109
1uF,50V,Elect.
C382 354761019
100uF,35V,Elect.
C386,C387 354742219
220uF,16V,Elect.
C461,C467 354742209
22uF,16V,Elect.
C469 354780109
1uF,50V,Elect.
C365,C366 374725634
ECQ-V50V-563J,Plastic film
C368,C468 374721534
ECQ-B50V-153J,Plastic film
C370,C470 374721544
ECQ-V50V-154J,Plastic film
C465,C466 374725634
ECQ-V50V-563J,Plastic film
Resistors
R386,R387 443521004
10ohm +/-5%,1/2W,Metal oxide
R381 5104383
N16RGL100KBT20F,Variable
Plug
P303B 25055441
NPLG-3P423
Shield plate
R381A 27150477
(VOL)
Socket
P304B 25051237
NSCT-12P1027
U3 Driver PC board(NAAF-7338-1B/1C/1D/1E)
REF. NO. PART NO DESCRIPTION
Transistors
Q501,Q502 2216154R2 or
2SC1622A(D18)
2216153R2
2SC1622A(D17)
Q503,Q603 2216175R2 or
KTC3875-GR
2213143R2 or
2SC2712-O
2213144R2 or
2SC2712-Y
2213145R2 or
2SC2712-GR
2216173R2 or
KTC3875-O
2216174R2
KTC3875-Y
Q504-Q506 2215975 or
KTA1266-GR
2211455
2SA1015-GR
Q507,Q607 2215985 or
KTC3198-GR
2211255
2SC1815-GR
Q601,Q602 2216154R2 or
2SC1622A(D18)
2216153R2
2SC1622A(D17)
Q604-Q606 2215975 or
KTA1266-GR
2211455
2SA1015-GR
Diodes
D501,D503 223234R2 or
1SS352,Chip
223269R2
1SS355,Chip
D601,D603 223234R2 or
1SS352,Chip
223269R2
1SS355,Chip
D502,D602 224490560R2 or
UDZ5.6B
224550560R2
UDZS5.6B
Capacitors
C501,C504 354742209
22uF,16V,Elect.
C505,C605 354742219
220uF,16V,Elect.
C509,C609 354741009
10uF,16V,Elect.
C5621,C562 354761019
100uF,35V,Elect.
C601,C604 354742209
22uF,16V,Elect.
Resistors
R512,R513 443523904
39ohm +/-5%,1/2W,Metal oxide
R514,R614 443523304
33ohm +/-5%,1/2W,Metal oxide
R515,R612 443523904
39ohm +/-5%,1/2W,Metal oxide
R561,R562 443522204
22ohm +/-5%,1/2W,Metal oxide
R613,R615 443523904
39ohm +/-5%,1/2W,Metal oxide
Sockets
P501B 25051237
NSCT-12P1027
P502B,P503B 25051526
NSCT-4P1313
U4 Headphone PC board(NAETC-7339-1B/1C/1D/1E)
REF. NO. PART NO DESCRIPTION
Resistor
R528,R628 443523914
390ohm +/-5%,1/2W,Metal oxide
Jack
P504 25045396
LGT1516-0101
Wire holder
JL501A 25051109
NSCT-5P896
Note
<PP>..........European model only
<DT>.........120V model only
<GT,GR>...220-230V model only
THE COMPONENTS IDENTIFIED BY MARK ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
