Onkyo R-801A Service Manual

R-801A
PARTS LIST
CIRCUIT SECTION 3
U5 Connection PC board(NAETC-7340-1B/1C/1D/1E)
REF. NO. PART NO DESCRIPTION
ICs
Q951 222780125JRC or
NJM78M12FA
222780125MIT or
M5F78M12L
222780125NEC
MPC78M12HF
Transistors
Q101 2216175R2 or
KTC3875-GR<PP>
2213143R2 or
2SC2712-O<PP>
2213144R2 or
2SC2712-Y<PP>
2213145R2 or
2SC2712-GR<PP>
2216173R2 or
KTC3875-O<PP>
2216174R2
KTC3875-Y<PP>
Capacitors
C952 354741009
10uF,16V,Elect.
C104 354780339
3.3uF,50V,Elect.
Resistor
R951 452530474
4.7ohm +/-5%,1/2W,Metal oxide
Plug
P104A 25055707
NPLG-11P663
Sockets
P102B,P103B 25051231
NSCT-6P1021
P101B 25051238
NSCT-13P1028
P105A 25052248
NSCT-15P2145
U6 Input/Output PC board(NAETC-7341-1B/1C/1D/1E)
REF. NO. PART NO DESCRIPTION
Jacks
P311 25045571 or
NPJ-6PDRW386
25045300
NPJ-6PDBL159
P781 25045504
NPJ-1PDBL319
Socket
P104B 25051236
NSCT-11P1026
U7 Display PC board(NADIS-7342-1B/1C/1D/1E)
REF. NO. PART NO DESCRIPTION
FL. Tube
Q705 212223
HNA-09SS27T
LES
D707 225338
SLR-332VR
D708 225340
SLR-332DU
Remote sensors
U701 241335 or
SPS-444-1
241341
SPS-444-1-E1
Capacitor
C726 353741009
10uF,16V,Elect.
Push switch
S702-S707 25035699
NPS-111-S662
Rotary Encoder
S701 25065622
EC11101200
Wire holder
JL703B 25051093
NSCT-9P880
JL701B,JL702B 25051094
NSCT-10P881
U8 Microprocessor PC board(NADG-7343-1B/1C/1D/1E)
REF. NO. PART NO DESCRIPTION
ICs
Q701 22241712R3
MPD78045FGF-133-3B9
Q702 22240239
TA7291S
Q704 22241297R2
BU1923F<PP>
Transistors
Q703 2216210R2 or
KRC104S
2214490R2
RN1404
Q706 2216230R2 or
KRA103S
2214540R2
RN2403
Diodes
D701,D702 22380260 or
RL1N4003
22380032 or
1SR139-100
22380035
GP104003E
D703,D704 223234R2 or
1SS352,Chip
223269R2
1SS355,Chip
D705,D706 224490510R2 or
UDZ5.1B,Zener
224550510R2
UDZS5.1B,Zener
Oscillators
X701 3010261
HC-49/U03 4.19M10P
X702 3010203
AF6146CG<PP>
Coils
L701 231237K220R2
NCH-1477
L702 231237K220R2
NCH-1477<PP>
Capacitors
C708 3000120
FMC0H104Z,EDL
C703 353744709
47uF,16V,Elect.
C705 353780109
1uF,50V,Elect.
C711 354780339
3.3uF,50V,Elect.
C715 353781009
10uF,50V,Elect.
C716 354721019
100uF,6.3V,Elect.
C721,C724 354721019
100uF,6.3V,Elect.<PP>
C722 374725614
ECQ-B50V-561J<PP>
C707 3060031
NTC-45P27
Socket
P701B 25052223
NSCT-27P2120
Wire holders
JL701A,JL702A 25051094
NSCT-10P881
JL703A 25051093
NSCT-9P880
JL704A 25051094
NSCT-10P881
Note
<PP>..........European model only
<DT>.........120V model only
<GT,GR>...220-230V model only
THE COMPONENTS IDENTIFIED BY MARK ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
