Onkyo R-801A Service Manual

R-801A
PARTS LIST
CIRCUIT PARTS 4
Note
<PP>..........European model only
<DT>.........120V model only
<GT,GR>...220-230V model only
THE COMPONENTS IDENTIFIED BY MARK ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE ONLY WITH PART NUMBER SPECIFIED.
U9 Power supply PC board(NAPS-7344-1B/1C/1D/1E)
REF. NO. PART NO DESCRIPTION
Transistors
Q901 2215830 or
KRC105M
2213640
DTC123JS
Diodes
D902-D905 22380260 or
RL1N4003
22380032 or
1SR139-100
22380035
GP104003E
D901,D906 223234R2 or
1SS352,Chip
223269R2
1SS355,Chip
D907 223234R2 or
1SS352,Chip
223269R2
1SS355,Chip
D908 224490510R2 or
UDZ5.1B,Zener
224550510R2
UDZS5.1B,Zener
Coils
L571,L671 231176S
S-1.3C
Capacitors
C904 354742219
220uF,16V,Elect.
C905 354741009
10uF,16V,Elect.
C901 3500196
RE275V-103M,Plastic film
C571,C671 374721034
ECQ-B50V-103J,Plastic
C573 374724734
ECQ-V50V-473J,Plastic
Resistors
R901 443521004
82ohm +/-5%,1/2W,Metal oxide<PP>
R906 443528204
10ohm +/-5%,1/2W,Metal oxide
R571,R671 453530564
5.6ohm +/-5%,1/2W,Metal
R901 453530564
5.6ohm +/-5%,1/2W,Metal<DT,GR,GT>
R907 431533355
RC1/2GFKUL-3.3M,Solid<DT>
Transformer
T902 2301464
NPT-1398D<DT>
2301465
NPT-1398G<GR,GT>
2301539
NPT-1398P<PP>
Relays
RL901 25065603 or
NRL-1P5A-DC9-152
25065601
NRL-1P5A-DC9-150
Terminal
P571 25060286
NTM-4PDML217
Jack
P572 25045567
NPJ-1PDBL382
Plug
P901A 25055676
NPLG-2P632
Fuse holders
F901A,F901B 25052133
NSCT-1P2031
Wire holders
JL502A 25051109
NSCT-5P896
JL931A 25051112
NSCT-8P899
JL932A 25051108
NSCT-4P895
Labels
F901C 29363040
T315mAL250V<PP>
29363040
T315mAL250V<GR>
29363040
T315mAL250V<GT>
29360667
LABEL(F)<DT>
