Onkyo RC-863M User Manual

10/31 PAGE
P603 SOCKET AS NSAS-9P2223 1 2009991412UL N
P603A WIRE HOL NSCT-9P900 1 25051113
P6080 PLUG NPLG-2P29 1 25055038
P6081 PLUG NPLG-2P29 1 25055038
P6082 PLUG NPLG-2P29 1 25055038
P6083 PLUG NPLG-2P29 1 25055038
P6084 PLUG NPLG-2P29 1 25055038
P6085 PLUG NPLG-2P29 1 25055038
P6086 PLUG NPLG-2P29 1 25055038
P6400B CRIMP AS CRIMP AS 1 20799165UL
P6401A CRIMP AS CRIMP AS 1 2069925162UL
P6402A CRIMP AS CRIMP AS 1 2069925199UL
P6403B CRIMP AS CRIMP AS 1 20799163UL
P6404B CRIMP AS CRIMP AS 1 20799164UL
P6600 SOCKET AS NSAS-7P2208 1 2009991397UL N
P6600A WIRE HOL NSCT-7P898 1 25051111
P951B PLUG NPLG-5P352 1 25055369
P952 SOCKET AS NSAS-3P2176 1 2009991365UL N
P952A WIRE HOL NSCT-3P894 1 25051107
P954A WIRE HOL NSCT-5P896 1 25051109
P954B WIRE HOL NSCT-5P896 1 25051109
RL643 RELAY NRL-1P10A-DC12-196 1 25065707
RL643 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
RL643 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
RL644 RELAY NRL-1P10A-DC12-196 1 25065707
RL644 or RELAY NRL-1P10A-DC12-197 ( 1) 25065708
RL644 or RELAY NRL-1P10A-DC12-198 ( 1) 25065709
U003 BACLA-1318-1A
: NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D5000 ZENER D DZ2J056M0L 1 224760560R2
D5000 or ZENER D UDZS5.6B ( 1) 224550560R2
D5001 ZENER D DZ2J056M0L 1 224760560R2
D5001 or ZENER D UDZS5.6B ( 1) 224550560R2
D5002 ZENER D DZ2J056M0L 1 224760560R2
D5002 or ZENER D UDZS5.6B ( 1) 224550560R2
D5003 ZENER D DZ2J056M0L 1 224760560R2
D5003 or ZENER D UDZS5.6B ( 1) 224550560R2
D5004 ZENER D DZ2J056M0L 1 224760560R2
D5004 or ZENER D UDZS5.6B ( 1) 224550560R2
D5005 ZENER D DZ2J056M0L 1 224760560R2
D5005 or ZENER D UDZS5.6B ( 1) 224550560R2
D5006 ZENER D DZ2J056M0L 1 224760560R2
D5006 or ZENER D UDZS5.6B ( 1) 224550560R2
Q5000 TR 2SC2713-BL 1 2213136R2
Q5001 TR 2SC2713-BL 1 2213136R2
Q5002 TR 2SC2713-BL 1 2213136R2
Q5003 TR 2SC2713-BL 1 2213136R2
Q5004 TR 2SC2713-BL 1 2213136R2
Q5005 TR 2SC2713-BL 1 2213136R2
Q5006 TR 2SC2713-BL 1 2213136R2
Q5010 TR 2SC2713-BL 1 2213136R2
Q5011 TR 2SC2713-BL 1 2213136R2
Q5012 TR 2SC2713-BL 1 2213136R2
Q5013 TR 2SC2713-BL 1 2213136R2
Q5014 TR 2SC2713-BL 1 2213136R2
Q5015 TR 2SC2713-BL 1 2213136R2
Q5016 TR 2SC2713-BL 1 2213136R2
Q5030 TR INA6006AP1-T111 1 2217980R2
Q5030 or TR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
Q5031 TR INA6006AP1-T111 1 2217980R2
Q5031 or TR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
Q5032 TR INA6006AP1-T111 1 2217980R2
Q5032 or TR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
Q5033 TR INA6006AP1-T111 1 2217980R2
Q5033 or TR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
Q5034 TR INA6006AP1-T111 1 2217980R2
Q5034 or TR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
Q5035 TR INA6006AP1-T111 1 2217980R2
Q5035 or TR 2SA1200-Y(2LONK_ZE) ( 1) 2217584R2
Q5036 TR INA6006AP1-T111 1 2217980R2
