22/31 PAGE
S7113 PUSH SW NPS-111-S681 1 25035718T
S7114 PUSH SW NPS-111-S681 1 25035718T
S7115 PUSH SW NPS-111-S681 1 25035718T
S7119 PUSH SW NPS-111-S681 1 25035718T
S7120 PUSH SW NPS-111-S681 1 25035718T
S7121 PUSH SW NPS-111-S681 1 25035718T
S7122 PUSH SW NPS-111-S681 1 25035718T
S7123 PUSH SW NPS-111-S681 1 25035718T
S7124 PUSH SW NPS-111-S681 1 25035718T
S7125 PUSH SW NPS-111-S681 1 25035718T
S7126 PUSH SW NPS-111-S681 1 25035718T
S7127 PUSH SW NPS-111-S681 1 25035718T
S7128 PUSH SW NPS-111-S681 1 25035718T
S7129 PUSH SW NPS-111-S681 1 25035718T
S7130 PUSH SW NPS-111-S681 1 25035718T
S7131 PUSH SW NPS-111-S681 1 25035718T
S7132 PUSH SW NPS-111-S681 1 25035718T
S7136 PUSH SW NPS-111-S681 1 25035718T
S7137 PUSH SW NPS-111-S681 1 25035718T
S7138 PUSH SW NPS-111-S681 1 25035718T
U008 BAHDM-1337-1A
: NSP
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D110 C-DIODE DA2J10100 1 223303R2
D110 or C-DIODE 1SS352 ( 1) 223234R2
D111 C-DIODE DA2J10100 1 223303R2
D111 or C-DIODE 1SS352 ( 1) 223234R2
D181 C-DIODE DA2J10100 1 223303R2
D181 or C-DIODE 1SS352 ( 1) 223234R2
D182 C-DIODE DA2J10100 1 223303R2
D182 or C-DIODE 1SS352 ( 1) 223234R2
D183 C-DIODE DA2J10100 1 223303R2
D183 or C-DIODE 1SS352 ( 1) 223234R2
D601 C-DIODE DA2J10100 1 223303R2
D601 or C-DIODE 1SS352 ( 1) 223234R2
D602 C-DIODE DA2J10100 1 223303R2
D602 or C-DIODE 1SS352 ( 1) 223234R2
D603 C-DIODE DA2J10100 1 223303R2
D603 or C-DIODE 1SS352 ( 1) 223234R2
D701 C-DIODE DA2J10100 1 223303R2
D701 or C-DIODE 1SS352 ( 1) 223234R2
D702 C-DIODE DA2J10100 1 223303R2
D702 or C-DIODE 1SS352 ( 1) 223234R2
D8100 C-DIODE DA2J10100 1 223303R2
D8100 or C-DIODE 1SS352 ( 1) 223234R2
D8145 ESD D AOZ8804ADI 1 225502R2
D8146 ESD D AOZ8804ADI 1 225502R2
D8347 DIODE DAN217T146 1 223285R2
D8347 or DIODE KDS123S ( 1) 223312R2
Q153 IC BR25S640FJ 1 22242761R2
Q153 or IC R1EX25064ASA00A ( 1) 22242581R2
Q153 or IC M95640-W MN6TP ( 1) 22242643R2
Q181 TR KRC105S 1 2217290R2
Q181 or TR RN1405 ( 1) 2214500R2
Q201 IC D808K013DPTP300 1 22242877R3 N
Q271 IC S-13A1A12-U5T1U3 1 22242841R2
Q272 IC BU33TD3WG-TR 1 22242715R2
Q273 IC S-1172B50-U5T1G 1 22242765R2
Q276 IC FP6861C-B1AS5CT 1 22242840R2
Q277 IC BU33TD3WG-TR 1 22242715R2
Q278 IC BU18TD3WG-TR 1 22242716R2
Q281 IC EM638165TSB-7G 1 22242775R2
Q281 or IC H57V6462GTR-60C ( 1) 22242888R3
Q282 IC EN25QH16-104HIP 1 222W 0130R2
Q301 IC PCM9211PTR 1 22242703R2
Q3105 IC MFI337S3959 1 22242820R2
Q351 IC PCM1681PW PR 1 22242697R2
Q601 TR KRC104S 1 2216210R2
Q601 or TR RN1404 ( 1) 2214490R2
Q701 IC MPD70F3746GJ-GAE-AX 1 222W0079R3
Q702 IC S-812C33AUA-C2N 1 22242222R2
