Video Resolution Chart
The following tables show how video signals at different resolutions are output by the AV receiver.
NTSC/PAL
✔: Output
*1
Available resolution:
[640 × 480 60/72/75 Hz]
[800 × 600 56/60/72/75 Hz]
[1024 × 768 60/70/75 Hz]
[1280 × 1024 60 Hz]
*2
The output is limited to 480p/576p for an effective signal in the effect of Macrovision.
*3
PC IN (Analog RGB) input signal is output at 720p resolution when you select “Analog” in the “Monitor Out” setting (➔ 43) and
“Through” in the “Resolution” setting (➔ 44).
HDMI Component S-Video
Composite
1080p 1080i 720p 480p/
576p
480i/
576i
1080p 1080i 720p 480p/
576p
480i/
576i
480i/576i
HDMI 1080p ✔
1080i ✔✔✔
720p ✔✔✔
480p/576p ✔✔✔✔
480i/576i ✔✔✔✔✔
Component 1080p ✔✔
1080i ✔✔✔ ✔✔
720p ✔✔✔ ✔✔
480p/576p ✔✔✔✔
✔
*2
✔
*2
✔
480i/576i ✔✔✔✔✔
✔
*2
✔
*2
✔✔
S-Video
Composite
480i/576i ✔✔✔✔✔
✔
*2
✔
*2
✔✔✔
PC IN (Analog RGB)
*1
✔✔✔✔
✔✔
*3
✔
*3
✔
*3
Output
Input
