Appendix
TX-RZ630/RZ730/RZ830
This test is each key(button) is working normally or not.
Setp1: Set volume 40
Setp2: [TV] + [ON/STANDBY]
Setp3: Push [BD/DVD]
Step4: Rotate [TONE +5] quickly and select “TEST 1-06”
Step5: When you push Each key(button),
The FL tube shows each key name.
Above sample: Push [BLUETOOTH] key.
Step6: Push [ON/STANDBY] key
Step7: Push [BD/DVD] key for exit key operation check mode(1-06)
And return “TEST 1-00”
Setp8: Push [ON/STANDBY] key for “ALL Clear” reset
and go to standby mode.
Key operation check
T
E
S
T
_
-
This Segment is blinked
T
E
S
T
1
- 0
0
K
E
Y
T
E
S
T
M
O
D
E
K
E
Y
O
F
F
B
L
U
E
T
O
O
T
H
T
E
S
T
1
- 0
6
O
n
/ S
t d
b
y
T
E
S
T
1
- 0
0
A
l l C
l e
a
r
