Onkyo TX-SR402 - Page 11

TX-SR402/8240/HT-R420
EXPLODED VIEWS-2
TX-SR402/8240/HT-R420
Q6064
Q6063
Q6062
Q6061
Q6060
Q6050
Q6051
Q6052
Q6054
Q6053
Q6050A
x10
A037
x10
A416
(L=85mm)
A417
(L=160mm)
<Fig-2>
<Fig-3>
U21
U22
A022
U26
A022
<Fig-1>
HT-R420 MDD, MDCTX-SR402/8240
HT-R420 MPA, MPT,MWT
FRONT PANEL INSIDE VIEW
A416
(L=85mm)
BLACK MODELS ONLY
[HT-R420(B)MDC, (B)MDD,
(B)MPA Only]
A415
(L=135mm)
BLACK MODELS ONLY
[HT-R420(B)MDC, (B)MDD,
(B)MPA ONLY]
A418
(L=215mm)
BLACK MODELS ONLY
[HT-R420(B)MDC, (B)MDD,
(B)MPA ONLY]
